The ultimate 16-core desktop CPU with 2nd gen AMD 3D V-Cache™ Technology that can do it all with incredible performance for the most demanding gamers and creators.
General
| Unit Calculated Weight | 0.153 kg |
| Unit Calculated Volume | 0.001835 cubm |
| Units per Shipping Box | 4 |
| Units per Pallet | 0 |
| Model number | 9950X3D |
| CPU Family name | AMD Ryzen 9 |
| Model | 100-100000719WOF |
| Summary | AMD Ryzen 9 9950X3D. Processor family: AMD Ryzen™ 9, Processor socket: Socket AM5, Processor lithography: 4 nm. Memory channels: Dual-channel, Maximum internal memory supported by processor: 192 GB, Memory types supported by processor: DDR5-SDRAM. On-board graphics card model: AMD Radeon Graphics, On-board graphics card base frequency: 2200 MHz. Market segment: Desktop, Supported instruction sets: AES, AVX, AVX 2.0, AVX-512, SSE, SSE2, SSE3, SSE4.1, SSE4.2, SSSE3. USB version: 3.2 Gen 2 (3.1 Gen 2) |
| Unit Box Height | 0.035 |
| Unit Box Length | 0.125 |
| Unit Box Width | 0.125 |
Processor
| Cooler included | No |
| Package type | Box |
| Processor base frequency | 4.3 GHz |
| Processor boost frequency | 5.7 GHz |
| Processor cache | 144 MB |
| Processor cache type | L2 & L3 |
| Processor cores | 16 |
| Processor family | AMD Ryzen™ 9 |
| Processor generation | AMD Ryzen 9000 Series |
| Processor lithography | 4 nm |
| Processor manufacturer | AMD |
| Processor model | 9950X3D |
| Processor operating modes | 64-bit |
| Processor socket | Socket AM5 |
| Processor threads | 32 |
| Thermal Design Power (TDP) | 170 W |
Memory
| ECC | Yes |
| Maximum internal memory supported by processor | 192 GB |
| Memory channels | Dual-channel |
| Memory clock speeds supported by processor | 3600/5600 MHz |
| Memory types supported by processor | DDR5-SDRAM |
Graphics
| Discrete graphics card | No |
| Discrete graphics card model | Not available |
| On-board graphics card | Yes |
| On-board graphics card base frequency | 2200 MHz |
| On-board graphics card model | AMD Radeon Graphics |
Features
| Market segment | Desktop |
| Maximum number of PCI Express lanes | 28 |
| PCI Express slots version | 5.0 |
| Supported instruction sets | AES/AVX/AVX 2.0/AVX-512/SSE/SSE2/SSE3/SSE4.1/SSE4.2/SSSE3 |
I/O configuration
| USB ports quantity | 4 |
| USB version | 3.2 Gen 2 (3.1 Gen 2) |
Operational conditions
| Minimum operating temperature | 95 °C |
