Highlights
| Product Highlights |
|
Features
| UPS Topology | Standby (Offline) |
| Output Power Capacity | 0.7 kVA |
| Output Power | 420 W |
| Waveform | Stepwise |
| Input Operation Voltage (min) | 161 V |
| Input Operation Voltage (max) | 284 V |
| Input Frequency | 46/70 Hz |
| Output Operation Voltage (min) | 161 V |
| Output Operation Voltage (max) | 284 V |
| Output Frequency | 50/60 Hz |
| Number of Input Phases | 1 |
| Number of Output Phases | 1 |
| Efficiency | 97% |
| Noise Level | 25 dB |
Ports & Interfaces
| AC Outlet Types | C3 coupler |
| AC Outlets Quantity | 4 AC outlet(s) |
| USB Port | Yes |
| USB Port Type | USB Type A/USB Type-C |
Battery
| Battery Capacity | 7 Ah |
| Battery Voltage | 12 V |
Design
| Form Factor | Tower |
| Product Colour | Black |
| Display Type | LED |
Operational Conditions
| Operating Temperature (T-T) | 0 - 40 °C |
Packaging Content
| Cables Included | USB cable |
| Quick Installation Guide | Yes |
Weight & Dimensions
| Width | 81 mm |
| Depth | 235 mm |
| Height | 263 mm |
| Weight | 3.9 kg |
Warranty and Other
| Warranty Terms | 24 months |
| Product Condition | Original |
| Manufacturer Datasheet | https://www.tdbaltic.ee/leaflets/EATON/3P700UI.pdf |
