EATON 920 Watts 230 VA Wave form type Sinewave LineInteractive Rack 1U 5P1150IRG2

Kainos tik partneriams Prisijungti B2B

EATON

Garantija: 24 mėn.

Terms and Conditions
30-day money-back guarantee
Shipping: 2-3 Business Days

Gamintojas: EATON

EATON 920 Watts 230 VA Wave form type Sinewave LineInteractive Rack 1U 5P1150IRG2

Unit Calculated Weight	19.2 kg
Unit Calculated Volume	0.058941 cubm
Units per Shipping Box	1
Summary	Eaton 5P1150IRG2. UPS topology: Line-Interactive, Output power: 920 W, Waveform: Sine. AC outlet types: C13 coupler, Power plug: C14 coupler, AC outlets quantity: 6 AC outlet(s). Battery technology: Sealed Lead Acid (VRLA), Battery capacity: 9 Ah, Battery voltage: 6 V. Form factor: Tower, Product colour: Black, Silver, Rack capacity: 1U. Certification: IEC/EN 62040-1 IEC/EN 62040-2 IEC/EN 62040-3 UL 1778 CSA-C22.2 CE UKCA Cm Ukr KCC cTUVus BIS
Unit Box Height	0.185
Unit Box Length	0.59
Unit Box Width	0.54
Model	5P Gen2

Automatic Voltage Regulation (AVR)	Yes
Efficiency	98.2 %
Heat dissipation	465 BTU/h
Input frequency	50/60 Hz
Input operation voltage (max)	294 V
Input operation voltage (min)	150 V
Noise level	35 dB
Number of input phases	1
Number of output phases	1
Output frequency	50/60 Hz
Output operation voltage (max)	240 V
Output power	920 W
UPS topology	Line-Interactive
Waveform	Sine

Battery capacity	9 Ah
Battery technology	Sealed Lead Acid (VRLA)
Battery voltage	6 V
Number of batteries supported	4

Operating altitude	0 - 3000 m
Operating relative humidity (H-H)	0 - 90 %
Operating temperature (T-T)	0 - 40 °C

Certification

IEC/EN 62040-1 IEC/EN 62040-2 IEC/EN 62040-3 UL 1778 CSA-C22.2 CE UKCA Cm Ukr KCC cTUVus BIS

Manual	Yes
Quick installation guide	Yes
