Sharp Vision. Swift Victory.
ROG Swift OLED PG34WCDN
The ROG Swift OLED PG34WCDN is the world's first RGB OLED gaming monitor*. It boasts a 34-inch 1800R-curved QD-OLED display that redefines speed with an astonishing 360Hz refresh rate and ultra-responsive 0.03ms gray-to-gray (GTG) response time. A host of other innovative features include ROG RGB Stripe Pixel technology for crisp, clear text, BlackShield™ film for enhanced durability and deeper black hues, and ASUS OLED Care Pro to prevent panel burn-in. With future-proof connectivity such as DisplayPort™ 2.1 UHBR20 and USB-C® with 90-watt Power Delivery, the PG34WCDN delivers unparalleled gaming and content-creation experiences.
- 34-inch WQHD QD-OLED 1800R monitor with 360Hz refresh rate and 0.03ms GTG response time
- RGB Stripe Pixel OLED panel with an RGB sub-pixel arrangement for sharp and clear text edges, accurate color reproduction, and higher-quality dynamic display performance
- BlackShield™ film increases the panel’s hardness for 2.5X better scratch resistance and boosts the perceived black level by up to 40% versus previous-gen QD-OLED panels
- VESA DisplayHDR™ 500 True Black compliance, 99% DCI-P3 gamut, true 10-bit color, and Delta E<2 color difference for astonishing HDR performance—perfect for photo and video editing
- ASUS OLED Care Pro with Neo Proximity Sensor precisely detects when a user is away and switches to a black screen to reduce the risk of burn-in
- DisplayWidget Center offers auto firmware updates and makes it easy to export and import settings to any device or copy pro streamers' configurations
- Extensive connectivity options include DisplayPort™ 2.1 UHBR20 (full 80Gbps bandwidth), HDMI® 2.1, and USB-C® with 90-watt Power Delivery
General
| Summary | ASUS ROG Swift OLED PG34WCDN. Display diagonal: 86.4 cm (34"), Display resolution: 3440 x 1440 pixels, HD type: Wide Quad HD, Display technology: QD-OLED, Response time: 0.03 ms, Native aspect ratio: 21:9, Viewing angle, horizontal: 178°, Viewing angle, vertical: 178°. Built-in USB hub, USB hub version: 3.2 Gen 1 (3.1 Gen 1). VESA mounting, Height adjustment. Product colour: Black |
| Unit Box Height | 0.5 |
| Unit Box Length | 0.985 |
| Unit Box Width | 0.2 |
| Model name | ROG Swift OLED PG34WCDN |
Display
| Anti-glare screen | Yes |
| Colour gamut standard | DCI-P3/sRGB |
| Contrast ratio (dynamic) | 1500000:1 |
| Contrast ratio (typical) | 1300:1 |
| DCI-P3 coverage | 99 % |
| Digital horizontal frequency | 27 - 625 kHz |
| Digital vertical frequency | 24 - 360 Hz |
| Display diagonal | 34 " |
| Display diagonal (metric) | 87 cm |
| Display number of colours | 1.073 billion colours |
| Display resolution | 3440 x 1440 pixels |
| Display technology | QD-OLED |
| HD type | Wide Quad HD |
| High Dynamic Range (HDR) supported | Yes |
| High Dynamic Range (HDR) technology | DisplayHDR True Black 500/High Dynamic Range 10 (HDR10) |
| LED backlight | Yes |
| Maximum refresh rate | 360 Hz |
| Native aspect ratio | 21:9 |
| Panel type | OLED |
| Pixel pitch | 0.231 x 0.231 mm |
| Response time | 0.03 ms |
| Response time measurement type | GTG (Gray to Gray) |
| Screen curvature rating | 1800R |
| Screen shape | Curved |
| sRGB coverage (typical) | 135 % |
| Touchscreen | No |
| Viewable size, horizontal | 800.06 mm |
| Viewable size, vertical | 337.06 mm |
| Viewing angle, horizontal | 178 ° |
| Viewing angle, vertical | 178 ° |
Performance
| AMD FreeSync | Yes |
| AMD FreeSync type | FreeSync Premium Pro |
| Flicker-free technology | Yes |
| Game mode | Yes |
| Low Blue Light technology | Yes |
| NVIDIA G-SYNC | Yes |
| NVIDIA G-SYNC type | G-SYNC Compatible |
| VESA Adaptive Sync support | Yes |
Multimedia
| Built-in camera | No |
| Built-in speaker(s) | No |
Design
| Feet colour | Black |
| Market positioning | Gaming |
| Product colour | Black |
Ports & interfaces
| Audio output | Yes |
| Built-in USB hub | Yes |
| DisplayPort version | 2.1 |
| DisplayPorts quantity | 1 |
| HDMI | Yes |
| HDMI ports quantity | 2 |
| HDMI version | 2.1 |
| Headphone out | Yes |
| Headphone outputs | 1 |
| USB hub version | 3.2 Gen 1 (3.1 Gen 1) |
| USB Power Delivery (USB PD) | Yes |
| USB Power Delivery up to | 90 W |
| USB Type-A downstream ports quantity | 3 |
| USB Type-C DisplayPort Alternate Mode | Yes |
| USB Type-C downstream ports quantity | 1 |
Ergonomics
| Adjustable height (max) | 110 mm |
| Cable lock slot | Yes |
| Cable lock slot type | Kensington |
| Height adjustment | Yes |
| Panel mounting interface | 100 x 100 mm |
| Swivel angle range | -30 - 30 ° |
| Swivelling | Yes |
| Tilt adjustment | Yes |
| Tilt angle range | -3 - 20 ° |
| VESA mounting | Yes |
| Wall mountable | Yes |
Power
| AC input frequency | 50/60 Hz |
| AC input voltage | 100 - 240 V |
| Energy consumption (HDR) per 1000 hours | 30 kWh |
| Energy consumption (SDR) per 1000 hours | 28 kWh |
| Energy efficiency class (HDR) | F |
| Energy efficiency class (SDR) | F |
| Energy efficiency scale | A to G |
| Power consumption (off) | 0.3 W |
| Power consumption (PowerSave) | 0.5 W |
| Power consumption (typical) | 85 W |
Weight & dimensions
| Depth (with stand) | 276.1 mm |
| Depth (without stand) | 107.9 mm |
| Height (with stand) | 562.7 mm |
| Height (without stand) | 373.3 mm |
| Weight (with stand) | 8300 g |
| Weight (without stand) | 5600 g |
| Width (with stand) | 812.8 mm |
| Width (without stand) | 812.8 mm |
Packaging data
| Package depth | 500 mm |
| Package height | 200 mm |
| Package type | Box |
| Package weight | 13700 g |
| Package width | 980 mm |
Sustainability
| Sustainability certificates | Forest Stewardship Council (FSC) Mix |
Other features
| Brand specific technologies | ASUS OLED Care |
Energy Efficiency
| Data Sheet (Link) | https://eprel.ec.europa.eu/api/product/2521723/fiches?language=EN |
| Energy efficiency class | F |
| EPREL Registration Number | 2521723 |
| EPREL Version Number | 3 |
