New Zen with AI
Elevate your experience with the sleek and sophisticated Zenbook 14 ultraportable. Its thin-and-light design houses the power of the latest AI-enabled AMD Ryzen™ AI 7 350 Processor, which make AI tools fly, along with AMD Radeon™ 860M graphics. A long-lasting battery ensures all-day power, and there’s a full complement of I/O ports for enhanced connectivity. Its 180° hinge allows easy sharing, and you can dive into a world of sensory delight with the vibrant ASUS Lumina OLED display1 and cutting-edge super-linear speakers, while embracing the environmentally conscious design that exudes eco-elegance.
- Windows 11 Home 64-bit
- AMD Ryzen AI 5 340 (2GHz)
- 35.6 cm (14") WUXGA 1920 x 1200 OLED
- 16GB LPDDR5x-SDRAM & 1000GB SSD
General
| Unit Calculated Weight | 2.4 kg |
| Unit Calculated Volume | 0.00861 cubm |
| Units per Shipping Box | 1 |
| Units per Pallet | 0 |
| Summary | ASUS Zenbook 14 OLED UM3406KA-QD066W. Product type: Laptop, Form factor: Clamshell. Processor family: AMD Ryzen AI 5, Processor model: 340, Processor frequency: 2 GHz. Display diagonal: 35.6 cm (14"), HD type: WUXGA, Display resolution: 1920 x 1200 pixels. Internal memory: 16 GB, Internal memory type: LPDDR5x-SDRAM. Total storage capacity: 1 TB, Storage media: SSD. On-board graphics card model: AMD Radeon 840M. Operating system installed: Windows 11 Home. Product colour: Black |
| Unit Box Height | 0.075 |
| Unit Box Length | 0.41 |
| Unit Box Width | 0.28 |
| Model name | 14 OLED |
| NB Family name | ZenBook Series |
Processor
| L2 cache | 6 MB |
| L3 cache | 16 MB |
| Processor boost frequency | 4.8 GHz |
| Processor cache type | L2 & L3 |
| Processor cores | 6 |
| Processor family | AMD Ryzen™ AI 5 |
| Processor frequency | 2 GHz |
| Processor generation | AMD Ryzen AI 300 Series |
| Processor manufacturer | AMD |
| Processor model | 340 |
| Processor threads | 12 |
Display
| Colour gamut | 100 % |
| Contrast ratio (typical) | 1000000:1 |
| Display brightness | 400 cd/m² |
| Display diagonal | 14 " |
| Display number of colours | 1.07 billion colours |
| Display resolution | 1920 x 1200 pixels |
| Display response rise/fall | 0.2 ms |
| Display surface | Gloss |
| HD type | WUXGA |
| High Dynamic Range (HDR) supported | Yes |
| High Dynamic Range (HDR) technology | DisplayHDR True Black 600 |
| Maximum display brightness (HDR) | 600 cd/m² |
| Maximum refresh rate | 60 Hz |
| Native aspect ratio | 16:10 |
| Panel type | OLED |
| RGB colour space | DCI-P3 |
| Touchscreen | No |
Design
| Certified refurbished | No |
| Colour name | Jade Black |
| Form factor | Clamshell |
| Housing material | Aluminium |
| Market positioning | Home |
| Product colour | Black |
| Product type | Laptop |
Neural processor unit (NPU)
| Copilot+ PC | No |
| Neural processor unit (NPU) | AMD Ryzen AI |
| NPU performance up to | 50 TOPs |
| Total processor performance up to | 59 TOPs |
Memory
| Internal memory | 16 GB |
| Internal memory type | LPDDR5x-SDRAM |
| Maximum internal memory | 16 GB |
| Memory form factor | On-board |
Storage
| Number of SSDs installed | 1 |
| NVMe | Yes |
| Optical drive type | No |
| SSD capacity | 1000 GB |
| SSD form factor | M.2 |
| SSD interface | PCI Express 4.0 |
| Storage media | SSD |
| Total SSDs capacity | 1000 GB |
| Total storage capacity | 1000 GB |
Graphics
| Discrete graphics card | No |
| Discrete graphics card model | Not available |
| On-board GPU manufacturer | AMD |
| On-board graphics card | Yes |
| On-board graphics card family | AMD Radeon |
| On-board graphics card model | AMD Radeon 840M |
Audio
| Audio system | Smart Amp |
| Built-in microphone | Yes |
| Speakers manufacturer | Harman Kardon |
Camera
| Front camera | Yes |
| Front camera HD type | Full HD |
| Front camera resolution | 1920 x 1080 pixels |
| Infrared (IR) camera | Yes |
| Privacy camera | Yes |
| Privacy type | Privacy shutter |
Network
| Antenna type | 2x2 |
| Bluetooth | Yes |
| Bluetooth version | 5.3 |
| Ethernet LAN | No |
| Mobile network connection | No |
| Top Wi-Fi standard | Wi-Fi 6E (802.11ax) |
| Wi-Fi standards | Wi-Fi 6E (802.11ax) |
Ports & interfaces
| Combo headphone/mic port | Yes |
| HDMI ports quantity | 1 |
| HDMI version | 2.1 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 1 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity | 1 |
| USB Type-C DisplayPort Alternate Mode | Yes |
| USB4 Gen 3x2 ports quantity | 1 |
Performance
| Repairability index | 9.4 |
Keyboard
| Copilot key | Yes |
| Keyboard backlit | Yes |
| Numeric keypad | No |
| Pointing device | NumberPad |
Software
| Microsoft Copilot | Yes |
| Operating system architecture | 64-bit |
| Operating system installed | Windows 11 Home |
| Trial software | 1-month trial for new Microsoft 365 customers. Credit card required, McAfee 30 days |
Battery
| Battery capacity | 75 Wh |
| Battery technology | Lithium-Ion (Li-Ion) |
| Number of battery cells | 4 |
Power
| AC adapter frequency | 50 - 60 Hz |
| AC adapter input voltage | 100 - 240 V |
| AC adapter output current | 3.25 A |
| AC adapter output voltage | 20 V |
| AC adapter power | 65 W |
| USB Power Delivery (USB PD) | Yes |
| USB Type-C charging port | Yes |
| USB Type-C required charging power (max) | 65 W |
| USB Type-C required charging power (min) | 45 W |
Security
| Face recognition | Yes |
| Password protection | Yes |
| Password protection type | BIOS/User |
| Trusted Platform Module (TPM) | Yes |
| Windows Hello | Yes |
Certificates
| Compliance certificates | REACH |
Sustainability
| Sustainability certificates | ENERGY STAR/EPEAT Gold |
Weight & dimensions
| Depth | 220.1 mm |
| Height | 14.9 mm |
| Weight | 1200 g |
| Width | 312.4 mm |
Packaging content
| AC adapter included | Yes |
| Bag included | Yes |
