(1) In the forearm with 20-degree angle, compared to a Logitech M650 mouse. (2) Requires Logi Options+ app, available for recent versions of Windows and macOS at logi.com/optionsplus. (3) Battery life may vary based on user and computing conditions. (4) Excludes plastic in receiver, printed wiring assembly, cables, and packaging. (5)Sound level comparison between MX Ergo S and MX Ergo. Left click dBA measured by the Logitech internal lab at 1m. (6) The device's basic functions will be supported without additional drivers for operating systems other than Windows and macOS.
General
| Unit Calculated Weight | 0.405 kg |
| Unit Calculated Volume | 0.001486 cubm |
| Units per Shipping Box | 4 |
| Units per Pallet | 0 |
| Summary | Logitech 910-007260. Form factor: Right-hand, Vertical design. Movement detection technology: Optical, Device interface: RF Wireless + Bluetooth, Movement resolution: 2048 DPI, Buttons type: Pressed buttons, Buttons quantity: 8, Scroll type: Trackball/Wheel, Acceleration (max): 10 G. Power source: Batteries. Product colour: Graphite |
| CnCode | 84716070 |
| Unit Box Height | 0.08 |
| Unit Box Length | 0.145 |
| Unit Box Width | 0.11 |
Mouse
| Acceleration (max) | 10 G |
| Bluetooth Low Energy (BLE) | Yes |
| Bluetooth version | 5.2 |
| Buttons durability (million clicks) | 3 |
| Buttons quantity | 8 |
| Buttons type | Pressed buttons |
| Connectivity technology | Wireless |
| Device interface | RF Wireless + Bluetooth |
| Frequency band | 2.4 GHz |
| Mouse tracking speed | 20 ips |
| Movement detection technology | Optical |
| Movement resolution | 2048 DPI |
| Number of programmable buttons | 6 |
| Number of scroll wheels | 1 |
| Polling rate | 88,125,133 Hz |
| Programmable mouse buttons | Yes |
| Purpose | Office |
| Scroll type | Trackball/Wheel |
| Scrolling directions | Vertical |
| Sensor type | TCOB |
Design
| Ergonomic design | Yes |
| Form factor | Right-hand |
| LED indicators | Yes |
| Material | Acrylonitrile butadiene styrene (ABS),Metal,Plastic,Rubber |
| Product colour | Graphite |
| Surface coloration | Monochromatic |
| Vertical design | Yes |
Power
| Battery capacity | 500 mAh |
| Battery life (max) | 500 h |
| Battery recharge time | 2 h |
| Battery technology | Lithium |
| Battery type | Built-in battery |
| Number of batteries supported | 1 |
| Power consumption | 500 mA |
| Power source | Batteries |
| Rechargeable | Yes |
| Service life of battery | 18 month(s) |
| USB Power Delivery (USB PD) | No |
| USB Type-C charging port | Yes |
| USB Type-C required charging power (max) | 2.5 W |
| USB Type-C required charging power (min) | 2.5 W |
Weight & dimensions
| Depth | 51.4 mm |
| Height | 132.5 mm |
| Weight | 259 g |
| Width | 99.8 mm |
Packaging data
| Package depth | 111.2 mm |
| Package height | 143 mm |
| Package type | Box |
| Package weight | 380 g |
| Package width | 79 mm |
| Quantity per pack | 1 pc(s) |
Packaging content
| Batteries included | Yes |
| Receiver included | Yes |
| Receiver type | Nano receiver |
| User guide | Yes |
| Wireless receiver interface | USB Type-A |
Other features
| Minimum system requirements | Bluetooth Low Energy Logi Bolt USB receiver Required: Available USB Port Internet access required to download optional customisation app Logi Options+ (2) |
| Packaging content | Advanced Wireless Trackball Logi Bolt Receiver Document (Cable not included) |
| Processor model | Nordic NRF52820 |
| Warranty period | 2 year(s) |
