- Online double conversion topology
- Intuitive user interface with an LCD panel that provides, on a single screen, clear information about UPS status
- Reliable UPS at an attractive price
- Provides more real power (watts) to protect more equipment with a 0.8 power factor
- Internal bypass and maintenance bypass are available as standards for service continuity
- Combo input (3:1 and 1:1) on the 10kVA, 15kVA, 20 kVA
- Long runtime with up to 4 optional EBM cabinets
- Extra-long runtime available with 3kVA, 10kVA and 20kVA XL models
- XL models with internal supercharger for extra-long runtime
- Communication through USB, RS232 serial or over the network with an optional communication card(Network card, ModBus/Jbus or Contacts/Serial cards)
- Compatible with Virtual environments (VMware, Hyper-V, Citrix Xen, Redhat)
- CE compliance certified by external laboratory (CB report from the TUV)
General
| Summary | Eaton 9E3000I. UPS topology: Double-conversion (Online), Output power capacity: 3 kVA, Output power: 2400 W. AC outlet types: C13 coupler, C19 coupler, Power plug: C20 coupler, AC outlets quantity: 7 AC outlet(s). Form factor: Tower, Product colour: Black. Certification: CE, CB, EAC. Safety: IEC/EN 62040-1, IEC/EN 62040 -2 |
| CnCode | 85044095 |
| Unit Box Height | 0.46 |
| Unit Box Length | 0.49 |
| Unit Box Width | 0.33 |
Features
| Efficiency (On-line mode) | 91 % |
| Input frequency | 40/70 Hz |
| Input operation voltage (max) | 300 V |
| Input operation voltage (min) | 176 V |
| Noise level | 37 dB |
| Output frequency | 50/60 Hz |
| Output operation voltage (max) | 240 V |
| Output operation voltage (min) | 208 V |
| Output power | 2400 W |
| Output power capacity | 3 kVA |
| Output voltage Total Harmonic Distortion (THD) | 2 % |
| Overload capacity (1 minute) | 130 % |
| Overload capacity (10 seconds) | 150 % |
| Overload capacity (3 seconds) | 150 % |
| UPS topology | Double-conversion (Online) |
Ports & interfaces
| AC outlet types | C13 coupler/C19 coupler |
| AC outlets quantity | 7 AC outlet(s) |
| Power plug | C20 coupler |
| Serial interface | Yes |
| Serial interface type | RS-232 |
| Serial ports quantity | 1 |
| USB port | Yes |
Design
| Form factor | Tower |
| Product colour | Black |
Operational conditions
| Operating temperature (T-T) | 0 - 40 °C |
Certificates
| Certification | CE, CB, EAC |
Safety regulation & standards
| Safety | IEC/EN 62040-1, IEC/EN 62040 -2 |
Weight & dimensions
| Depth | 399 mm |
| Height | 190 mm |
| Weight | 24200 g |
| Width | 330 mm |
