3-port USB 3.1 Gen 1 (5 Gbps) hub
HDMI port with UHD 4K @30 Hz support
VGA Full HD video port
Audio stereo 3.5 mm output
100W USB Type-C Power Delivery port
SD and MicroSD card reader/writer
Durable premium style metal housing
- 7-in-1: USB3 hub, 4K HDMI and Full HD VGA video, stereo audio, Gigabit LAN, card reader and USB Type-C PD 100W charge support
- Fast Gigabit networking and Superspeed USB 3.0 data transfer
- Practical card reader, video and audio outputs
- Plug & Play
General
| Summary | Gembird A-CM-COMBO7-01. Host interface: USB 3.2 Gen 1 (3.1 Gen 1) Type-A, USB Power Delivery up to: 100 W. Product colour: Grey, Compatible memory cards: MicroSD (TransFlash), SD, Maximum refresh rate: 30 Hz. Power supply: 100 W, Power supply type: USB, Power consumption (typical): 0.5 W. Width: 130 mm, Depth: 198 mm, Height: 56 mm. Package width: 85 mm, Package depth: 190 mm, Package height: 21 mm |
| Unit Box Height | 0.02 |
| Unit Box Length | 0.21 |
| Unit Box Width | 0.085 |
| Model | A-CM-COMBO7-01 |
Ports & interfaces
| HDMI ports quantity | 1 |
| HDMI version | 2.0 |
| Host interface | USB 3.2 Gen 1 (3.1 Gen 1) Type-A |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 3 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity | 1 |
| USB Power Delivery (USB PD) | Yes |
| USB Power Delivery revision | 3.0 |
| USB Power Delivery up to | 100 W |
| VGA (D-Sub) ports quantity | 1 |
Network
| Ethernet LAN (RJ-45) ports | 1 |
Performance
| Card reader integrated | Yes |
| Compatible memory cards | MicroSD (TransFlash)/SD |
| Housing material | Metal |
| Hub interfaces | 3.5mm/HDMI/RJ-45/USB 3.2 Gen 1 (3.1 Gen 1) Type-A/USB 3.2 Gen 1 (3.1 Gen 1) Type-C/VGA |
| Maximum refresh rate | 30 Hz |
| Product colour | Grey |
Power
| Power consumption (typical) | 0.5 W |
| Power supply | 100 W |
| Power supply type | USB |
Weight & dimensions
| Depth | 198 mm |
| Height | 56 mm |
| Weight | 90 g |
| Width | 130 mm |
Packaging data
| Package depth | 190 mm |
| Package height | 21 mm |
| Package weight | 155 g |
| Package width | 85 mm |
Other features
| Cable length | 0.15 m |
ELKO Logistics Data
| Product Net Weight | 0.09 kg |
| Unit Calculated Weight | 0.144 kg |
| Units per Shipping Box | 1 |
ELKO Internal Logistics Data
| Shipping Box Depth | 21 cm |
| Shipping Box Height | 2 cm |
| Shipping Box Weight | 0.144 kg |
| Shipping Box Width | 8.5 cm |
| Unit Calculated Volume | 0.000357 cubm |
