ARCTIC’s versatile assortment of Fans is both quiet and powerful. We have the right options for any application or need, in sizes from 80 to 140 mm. Plus, our Fans are equipped with state-of-the-art engine technology, innovative fan blades and high-quality bearings, making them particularly durable and efficient.
General
| Summary | ARCTIC BioniX P14 A-RGB - 3 Pack 140 mm PWM Fan with Daisy Chain. Type: Fan, Fan diameter: 14 cm, Rotational speed (min): 400 RPM, Rotational speed (max): 2500 RPM, Airflow: 186 m³/h, Maximum air pressure: 5.4 mmH2O, Bearing type: Fluid Dynamic Bearing (FDB). Voltage: 12 V. Width: 140 mm, Depth: 140 mm, Height: 28 mm. Product colour: Black |
| CnCode | 84145925 |
| Unit Box Height | 0.095 |
| Unit Box Length | 0.179 |
| Unit Box Width | 0.145 |
| Model name | BioniX P14 A-RGB - 3 Pack 140 mm PWM Fan with Daisy Chain |
Performance
| Airflow | 186 m³/h |
| Bearing type | Fluid Dynamic Bearing (FDB) |
| Fan diameter | 140 mm |
| Maximum air pressure | 5.4 mmH2O |
| Maximum airflow | 110 cfm |
| Operating temperature (T-T) | 0 - 40 °C |
| Pulse-width modulation (PWM) support | Yes |
| Quantity per pack | 3 pc(s) |
| Rotational speed (max) | 2500 RPM |
| Rotational speed (min) | 400 RPM |
| Suitable location | Computer case |
| Type | Fan |
Design
| Fan connector | 4-pin |
| Illumination colour | Blue/Green/Red |
| Illumination LED | Yes |
| LED connector type | 3-pin |
| Number of LEDs | 16 |
| Product colour | Black |
Power
| Fan current | 0.39 A |
| LED current | 0.6 A |
| LED voltage | 5 V |
| Starting voltage | 5 V |
| Voltage | 12 V |
Weight & dimensions
| Cable length | 0.4 m |
| Depth | 140 mm |
| Height | 28 mm |
| Package depth | 144 mm |
| Package height | 93 mm |
| Package weight | 928 g |
| Package width | 178 mm |
| Width | 140 mm |
Packaging content
| Number of screws | 12 |
| Package type | Box |
| Screws included | Yes |
