Effortlessly Streamline Your Printing
Superior and High-efficiency Output
A4 printing speed up to 22 pages per minute, together with 3-in-1 print, copy, scan function, which easily meet office working requirements
One-step Driver Installation,Easy to Use
The driver can be installed in one step without complex procedure,helping user enjoy worry-free operations
Convenient Mobile Printing with Pantum App
Support AirPrint, Mopria™ Print Service, Mopria Scan,Wi-Fi direct connection,and Pantum App, enabling users to enjoy wireless printing from various mobile devices
Excellent Compatibility with 2.4G/5G Dual-band Wi-Fi
Support 2.4G/5G dual-band Wi-Fi, compatible with 5G version routers, and have better applicability, which can provide a flexible and convenient mobile printing experience
Performance and Configuration Upgrade
The memory of this series is upgraded to 256MB and equipped with an 800MHz high-speed processor, which can smoothly handle large file printing and avoid freezing
Equipped with Robust Metal Frame inside
Strong and durable support to ensure the stability of the printer
- One step driver installation , new product comes with a USB cable
- 2.4Ghz/5Ghz Dual-band Wi-Fi support
- Bluetooth to identify and connect closest printer with the common wifi
- Connect to printer hotspot directly
- Convenient mobile printing
- Pantum app supports the direct printing of office documents
General
| Unit Calculated Weight | 9.3 kg |
| Unit Calculated Volume | 0.064923 cubm |
| Summary | Pantum BM2300NW. Print technology: Laser, Printing: Mono printing. Copying: Mono copying, Maximum copy resolution: 600 x 600 DPI. Scanning: Colour scanning, Optical scanning resolution: 1200 x 1200 DPI. Duplex functions: Copy, Print, Scan. Maximum ISO A-series paper size: A4. Wi-Fi. Direct printing. Product colour: White |
| Unit Box Height | 0.335 |
| Unit Box Length | 0.51 |
| Unit Box Width | 0.38 |
| Model | BM2300NW |
Printing
| Duplex printing | Yes |
| Duplex printing mode | Manual |
| Print speed (black, normal quality, A4/US Letter) | 22 ppm |
| Print technology | Laser |
| Printing | Mono printing |
Copying
| Copier resize | 20 - 400 % |
| Copy speed (black, normal quality, A4) | 22 cpm |
| Copying | Mono copying |
| Maximum copy resolution | 600 x 600 DPI |
| Maximum number of copies | 99 copies |
| Time to first copy (black, normal) | 10 s |
Scanning
| Maximum scan area | 216 x 297 mm |
| Optical scanning resolution | 1200 x 1200 DPI |
| Scan to | E-mail/FTP/PC/SMB |
| Scanner type | Flatbed scanner |
| Scanning | Colour scanning |
Fax
| Faxing | No |
Features
| Duplex functions | Copy/Print/Scan |
| Maximum duty cycle | 10000 pages per month |
| Number of print cartridges | 1 |
| Page description languages | GDI |
| Printing colours | Black |
| Recommended duty cycle | 250 - 2000 pages per month |
Input & output capacity
| Total input capacity | 150 sheets |
| Total output capacity | 100 sheets |
Paper handling
| ISO A-series sizes (A0...A9) | A4/A5/A6 |
| ISO B-series sizes (B0...B9) | B5/B6 |
| ISO C-series sizes (C0...C9) | C5/C6 |
| Maximum ISO A-series paper size | A4 |
| Paper tray media types | Card stock/Envelopes/Labels/Plain paper/Thick paper |
| Paper tray media weight | 60 - 163 g/m² |
Ports & interfaces
| Direct printing | Yes |
| USB port | Yes |
Network
| Bluetooth | Yes |
| Ethernet LAN | Yes |
| Wi-Fi | Yes |
Performance
| Built-in processor | Yes |
| Internal memory | 256 MB |
| Processor frequency | 800 MHz |
| Sound pressure level (copying) | 54 dB |
| Sound pressure level (printing) | 52 dB |
| Sound pressure level (scanning) | 54 dB |
| Sound pressure level (standby) | 30 dB |
Design
| Market positioning | Business |
| Product colour | White |
Power
| AC input frequency | 50/60 Hz |
| AC input voltage | 220 - 240 V |
| Power consumption (printing) | 370 W |
| Power consumption (ready) | 45 W |
| Power consumption (sleep) | 2.5 W |
System requirements
| Linux operating systems supported | Ubuntu 16.04/Ubuntu 18.04 LTS/Ubuntu 20.04 LTS/Ubuntu 22.04 |
| Mac operating systems supported | Mac OS X 10.10 Yosemite/Mac OS X 10.11 El Capitan/Mac OS X 10.12 Sierra/Mac OS X 10.13 High Sierra/Mac OS X 10.15 Catalina/Mac OS X 12.0 Monterey/Mac OS X 13.0 Ventura |
| Mobile operating systems supported | Android/Android 12.0/Android 6.0 |
| Server operating systems supported | Windows Server 2012/Windows Server 2016/Windows Server 2019 |
| Windows operating systems supported | Windows 10/Windows 11/Windows 7/Windows 8.1 |
Operational conditions
| Operating relative humidity (H-H) | 20 - 80 % |
| Operating temperature (T-T) | 10 - 32 °C |
Weight & dimensions
| Depth | 396 mm |
| Height | 249 mm |
| Weight | 7500 g |
| Width | 297.5 mm |
Packaging data
| Package depth | 512 mm |
| Package height | 331 mm |
| Package weight | 9200 g |
| Package width | 377 mm |
