The Club 3D Mini DisplayPort™ to DisplayPort™ 1.4 cable enables the connection of your Mini DisplayPort™ supported (Gaming) PC or Laptop to an (Ultra) High Resolution Monitor or other DisplayPort™ supported device. It features a locking DisplayPort™ connector providing a secure, dependable connection. Simply press the built-in one- touch latch button to unlock the connector. The soft UltraFlex jacket protects the cable from bends and deformation damage. The Cable is fully Bi-Directional.
Features:
* Fully DisplayPort™ Version 1.4 Compliant, HBR3, 32.4Gbps
* Support for Display Stream Compression (DSC) 1.2
* Support for Forward Error Correction
* Support for up to 32 Inline Audio Channels
* Downwards compatible to older Displayport standards
* Support resolutions up to 8K @ 60Hz or 2 x 4K @ 60Hz
* Fully Bi-Directional
General
| Unit Calculated Weight | 0.13 kg |
| Unit Calculated Volume | 0.0009461 cubm |
| Units per Shipping Box | 1 |
| Summary | CLUB3D Mini DisplayPort to DisplayPort 1.4 HBR3 8K60Hz Cable, 2 Meter / 6.56 Feet. Cable length: 2 m, Connector 1: Mini Displayport, Connector 2: Displayport. Compliance certificates: RoHS, Certification: ROHS, CE, FCC. Weight: 93 g. Package width: 145 mm, Package depth: 45 mm, Package height: 145 mm. Quantity per pack: 1 pc(s) |
| Unit Box Height | 0.045 |
| Unit Box Length | 0.145 |
| Unit Box Width | 0.145 |
| Model name | Mini DisplayPort to DisplayPort 1.4 HBR3 8K60Hz Cable, 2 Meter / 6.56 Feet |
Features
| 3D | Yes |
| Cable length | 2 m |
| Cable type | Round cable |
| Connector 1 | mini DisplayPort |
| Connector 1 form factor | Straight |
| Connector 1 gender | Male |
| Connector 2 | DisplayPort |
| Connector 2 form factor | Straight |
| Connector 2 gender | Male |
| Connector contacts plating | Gold |
| Connector gender | Male/Male |
| Data transfer rate | 32.4 Gbit/s |
| Display Stream Compression (DSC) | Yes |
| Display Stream Compression (DSC) version | 1.2 |
| DisplayPort version | 1.4 |
| Maximum refresh rate | 120 Hz |
| Maximum resolution | 7680 x 4320 pixels |
| Number of shielding layers | 3 |
| Plug and Play | Yes |
| Product colour | Black |
| Supported graphics resolutions | 3840 x 2160/7680 x 4320 |
| Supported video modes | 2160p/4320p |
Certificates
| Certification | ROHS, CE, FCC |
| Compliance certificates | RoHS |
Weight & dimensions
| Weight | 93 g |
Packaging data
| Package depth | 45 mm |
| Package height | 145 mm |
| Package type | Box |
| Package width | 145 mm |
| Paper/cardboard packaging weight | 63 g |
| Plastic packaging weight | 5 g |
| Total paper/cardboard packaging weight | 0 g |
| Total plastic packaging weight | 0 g |
Packaging content
| Quantity per pack | 1 pc(s) |
Logistics data
| Harmonized System (HS) code | 8544 4290 |
Other features
| Length | 2000 mm |
