- Ultra-narrow bezel , elegant appearance, plastic base
- 178°H/178°V extra-wide viewing angle for overall viewing performance
- High fidelity digital processing for a brilliant and vivid video
- Support multiple signal inputs such as HDMI, VGA
- 100Hz high refresh rate, eliminates picture lagging
General
| Unit Calculated Weight | 3.75 kg |
| Product Net Weight | 2.79 kg |
| Unit Calculated Volume | 0.0244 cubm |
| Units per Pallet | 0 |
| Summary | Dahua Technology LM24-A200Y. Display diagonal: 60.5 cm (23.8"), Display resolution: 1920 x 1080 pixels, HD type: Full HD, Display technology: LED, Response time: 10 ms, Native aspect ratio: 16:9, Viewing angle, horizontal: 178°, Viewing angle, vertical: 178°. VESA mounting. Product colour: Black |
| Unit Box Height | 0.4 |
| Unit Box Length | 0.61 |
| Unit Box Width | 0.1 |
| Model name | DHI-LM24-A200Y |
| Model | DHI-LM24-A200Y |
Display
| Backlight type | Edge LED |
| Colour depth | 8 bit |
| Colour gamut standard | NTSC |
| Contrast ratio (typical) | 3000:1 |
| Display brightness (typical) | 250 cd/m² |
| Display diagonal | 23.8 " |
| Display diagonal (metric) | 61 cm |
| Display resolution | 1920 x 1080 pixels |
| Display technology | LED |
| Haze rate | 25 % |
| HD type | Full HD |
| LED backlight | Yes |
| Maximum refresh rate | 100 Hz |
| Native aspect ratio | 16:9 |
| NTSC coverage (typical) | 72 % |
| Panel type | VA |
| Pixel density | 92.55 ppi |
| Pixel pitch | 0.2745 x 0.2745 mm |
| Response time | 10 ms |
| Screen shape | Flat |
| Supported graphics resolutions | 1920 x 1080 (HD 1080) |
| Supported video modes | 1080p |
| Touchscreen | No |
| Viewable size, horizontal | 527.04 mm |
| Viewable size, vertical | 296.46 mm |
| Viewing angle, horizontal | 178 ° |
| Viewing angle, vertical | 178 ° |
Performance
| AMD FreeSync | No |
| NVIDIA G-SYNC | No |
Multimedia
| Built-in camera | No |
| Built-in speaker(s) | No |
Design
| Feet colour | Black |
| Frameless design | Yes |
| Illuminated stand | No |
| Market positioning | Office |
| Product colour | Black |
Ports & interfaces
| Built-in USB hub | No |
| HDMI | Yes |
| HDMI ports quantity | 1 |
| HDMI version | 1.4 |
| Headphone out | No |
| VGA (D-Sub) ports quantity | 1 |
Network
| Bluetooth | No |
| Wi-Fi | No |
Ergonomics
| Height adjustment | No |
| Panel mounting interface | 75 x 75 mm |
| Plug and Play | Yes |
| Tilt adjustment | Yes |
| Tilt angle range | -5 - 15 ° |
| VESA mounting | Yes |
| Wall mountable | Yes |
Power
| AC adapter output voltage | 12 V |
| Energy consumption (SDR) per 1000 hours | 17 kWh |
| Energy efficiency class (HDR) | Not available |
| Energy efficiency class (SDR) | E |
| Energy efficiency scale | A to G |
| External power adapter | Yes |
| Input current | 2.5 A |
| Power consumption (max) | 16 W |
| Power consumption (off) | 0.1 W |
| Power consumption (standby) | 0.1 W |
| Power consumption (typical) | 16 W |
| Power supply type | External |
Operational conditions
| Operating relative humidity (H-H) | 10 - 90 % |
| Operating temperature (T-T) | 0 - 40 °C |
| Storage relative humidity (H-H) | 5 - 90 % |
| Storage temperature (T-T) | -20 - 60 °C |
Weight & dimensions
| Depth (without stand) | 41.3 mm |
| Height (without stand) | 320.4 mm |
| Weight (with stand) | 2790 g |
| Width (without stand) | 539.2 mm |
Packaging data
| Package depth | 101 mm |
| Package height | 405 mm |
| Package weight | 3750 g |
| Package width | 612 mm |
Packaging content
| Cables included | HDMI |
| Power adapter included | Yes |
| Stand included | Yes |
Other features
| Automatic brightness control | No |
| Compliance certificates | CE/Electromagnetic Compatibility (EMC) |
| E-manual | Yes |
Energy Efficiency
| Data Sheet (Link) | https://eprel.ec.europa.eu/api/product/2139338/fiches?language=EN |
| Energy efficiency class | E |
| EPREL Registration Number | 2139338 |
| EPREL Version Number | 1 |
