- Suitable for continuous 24/7 operation
- Micro bezel design, elegant appearance, ultra-light base
- 178°H/178°V extra-wide viewing angle for overall viewing performance
- Support multiple signal inputs including HDMI and VGA
- Low energy consumption, long service life
General
| Unit Calculated Weight | 4.8 kg |
| Product Net Weight | 3.2 kg |
| Unit Calculated Volume | 0.03063 cubm |
| Summary | Dahua Technology LM24-H200. Display diagonal: 60.5 cm (23.8"), Display resolution: 1920 x 1080 pixels, HD type: Full HD, Display technology: LED, Response time: 8 ms, Native aspect ratio: 16:9, Viewing angle, horizontal: 178°, Viewing angle, vertical: 178°. Built-in speaker(s). VESA mounting. Product colour: Black |
| Unit Box Height | 0.405 |
| Unit Box Length | 0.605 |
| Unit Box Width | 0.125 |
| Model name | LM24-H200 |
| Model | DHI-LM24-H200 |
Display
| Contrast ratio (typical) | 3000:1 |
| Display brightness (typical) | 250 cd/m² |
| Display diagonal | 23.8 " |
| Display number of colours | 16.7 million colours |
| Display resolution | 1920 x 1080 pixels |
| Display technology | LED |
| HD type | Full HD |
| Maximum refresh rate | 60 Hz |
| Native aspect ratio | 16:9 |
| Response time | 8 ms |
| Screen shape | Flat |
| Touchscreen | No |
| Viewing angle, horizontal | 178 ° |
| Viewing angle, vertical | 178 ° |
Performance
| AMD FreeSync | No |
| NVIDIA G-SYNC | No |
Multimedia
| Built-in camera | No |
| Built-in speaker(s) | Yes |
| Number of speakers | 2 |
| RMS rated power | 3 W |
Design
| Market positioning | Office |
| Product colour | Black |
Ports & interfaces
| Built-in USB hub | No |
| HDMI | Yes |
| HDMI ports quantity | 1 |
| Headphone out | Yes |
| VGA (D-Sub) ports quantity | 1 |
Ergonomics
| Height adjustment | No |
| Panel mounting interface | 100 x 100 mm |
| VESA mounting | Yes |
Power
| Energy consumption (SDR) per 1000 hours | 17 kWh |
| Energy efficiency class (SDR) | E |
| Energy efficiency scale | A to G |
| European Product Registry for Energy Labelling (EPREL) code | 1263652 |
| Power consumption (standby) | 0.5 W |
| Power consumption (typical) | 24 W |
Operational conditions
| Operating relative humidity (H-H) | 20 - 80 % |
| Operating temperature (T-T) | 0 - 40 °C |
Weight & dimensions
| Depth (without stand) | 47 mm |
| Height (without stand) | 326.4 mm |
| Weight (with stand) | 3200 g |
| Width (without stand) | 541.8 mm |
Packaging data
| Package depth | 405 mm |
| Package height | 125 mm |
| Package weight | 4500 g |
| Package width | 606 mm |
Packaging content
| Cables included | AC/HDMI |
Energy Efficiency
| Data Sheet (Link) | https://eprel.ec.europa.eu/api/product/1263652/fiches?language=EN |
| Energy efficiency class | E |
| EPREL Registration Number | 1263652 |
| EPREL Version Number | 4 |
