- The 2560×1440 resolution produces clearer and more vivid pictures.
- • 1ms fast response time with no image blurring or ghosting.
- • Images are delivered in excellent color accuracy with 95% DCI-P3 color coverage for you to see your work in vibrant, consistent colors.
- • With a high refresh rate that reaches up to 200Hz, images and videos are rendered with smoothness and fluidity.
- • Hardware-based anti-blue light flicker-free technology reduces visual fatigue and provides better eye protection during prolonged
- use.
- • Adjust the rotating lift base to the ideal working position for greatercomfort.
General
| Unit Calculated Weight | 7 kg |
| Product Net Weight | 5.6 kg |
| Unit Calculated Volume | 0.05712 cubm |
| Units per Pallet | 0 |
| Summary | Dahua Technology DHI-LM27-E331AY. Display diagonal: 68.6 cm (27"), Display resolution: 2560 x 1440 pixels, HD type: Quad HD, Display technology: LED, Native aspect ratio: 16:9, Viewing angle, horizontal: 178°, Viewing angle, vertical: 178°. VESA mounting, Height adjustment. Product colour: Black |
| Unit Box Height | 0.51 |
| Unit Box Length | 0.7 |
| Unit Box Width | 0.16 |
| Model name | DHI-LM27-E331AY |
| Model | DHI-LM27-E331AY |
Display
| Backlight type | Edge LED |
| Contrast ratio (typical) | 1000:1 |
| DCI-P3 coverage | 95 % |
| Display brightness (typical) | 300 cd/m² |
| Display diagonal | 27 " |
| Display number of colours | 1.07 billion colours |
| Display resolution | 2560 x 1440 pixels |
| Display technology | LED |
| Haze rate | 25 % |
| HD type | Quad HD |
| High Dynamic Range (HDR) supported | Yes |
| High Dynamic Range (HDR) technology | High Dynamic Range 10 (HDR10) |
| LED backlight | Yes |
| Maximum refresh rate | 200 Hz |
| Native aspect ratio | 16:9 |
| Panel type | IPS |
| Pixel pitch | 0.2331 x 0.2331 mm |
| Response time (MPRT) | 1 ms |
| Screen shape | Flat |
| Surface hardness | 3H |
| Touchscreen | No |
| Viewable size, horizontal | 596.74 mm |
| Viewable size, vertical | 335.66 mm |
| Viewing angle, horizontal | 178 ° |
| Viewing angle, vertical | 178 ° |
Performance
| Flicker-free technology | Yes |
| Low Blue Light technology | Yes |
Multimedia
| Built-in camera | No |
| Built-in speaker(s) | No |
Design
| Market positioning | Gaming |
| Product colour | Black |
Ports & interfaces
| Built-in USB hub | No |
| DisplayPort out version | 1.4 |
| DisplayPort version | 1.4 |
| DisplayPorts quantity | 2 |
| HDMI | Yes |
| HDMI ports quantity | 2 |
| HDMI version | 2.1 |
| Headphone out | Yes |
Ergonomics
| Adjustable height (max) | 110 mm |
| Height adjustment | Yes |
| Panel mounting interface | 100 x 100 mm |
| Pivot angle | -90 - 90 ° |
| Swivel angle range | -20 - 20 ° |
| Swivelling | Yes |
| Tilt adjustment | Yes |
| Tilt angle range | -5 - 15 ° |
| VESA mounting | Yes |
Power
| Energy consumption (SDR) per 1000 hours | 26 kWh |
| Energy efficiency class (HDR) | G |
| Energy efficiency class (SDR) | F |
| Power consumption (max) | 30 W |
| Power consumption (off) | 0.3 W |
| Power consumption (standby) | 0.5 W |
| Power consumption (typical) | 28 W |
| Power supply type | Internal |
Operational conditions
| Operating relative humidity (H-H) | 10 - 85 % |
| Operating temperature (T-T) | 0 - 40 °C |
| Storage relative humidity (H-H) | 5 - 90 % |
| Storage temperature (T-T) | -20 - 60 °C |
Weight & dimensions
| Depth (with stand) | 70.7 mm |
| Height (with stand) | 362.5 mm |
| Weight (with stand) | 5600 g |
| Width (with stand) | 613.8 mm |
Packaging data
| Package depth | 159 mm |
| Package height | 505 mm |
| Package weight | 7200 g |
| Package width | 704 mm |
Packaging content
| Cables included | AC/DisplayPort |
| Manual | Yes |
| Stand included | Yes |
Energy Efficiency
| Data Sheet (Link) | https://eprel.ec.europa.eu/api/product/2464746/fiches?language=EN |
| Energy efficiency class | F |
| EPREL Registration Number | 2464746 |
| EPREL Version Number | 1 |
