- IPS panel for wide viewing angles with 3-sided frameless design;
- Rich interfaces, including USB HUB and type C. 65W.Type-C can support reverse charging;
- 178°H/178°V extra-wide viewing angle for overall viewing performance;
- The height and angle can be adjusted to meet different needs.
General
| Unit Calculated Weight | 8.1 kg |
| Product Net Weight | 5.4 kg |
| Unit Calculated Volume | 0.0655266 cubm |
| Summary | Dahua Technology LM27-U401A. Display diagonal: 68.6 cm (27"), Display resolution: 3840 x 2160 pixels, HD type: Quad HD, Display technology: LED, Response time: 5 ms, Native aspect ratio: 16:9, Viewing angle, horizontal: 178°, Viewing angle, vertical: 178°. Built-in USB hub. VESA mounting, Height adjustment. Product colour: Black |
| Unit Box Height | 0.478 |
| Unit Box Length | 0.703 |
| Unit Box Width | 0.195 |
| Model name | LM27-U401A |
| Model | DHI-LM27-U401A |
Display
| Backlight type | Edge LED |
| Colour gamut standard | DCI-P3/NTSC/sRGB |
| Contrast ratio (typical) | 1000:1 |
| DCI-P3 coverage | 95 % |
| Display brightness (typical) | 300 cd/m² |
| Display diagonal | 27 " |
| Display diagonal (metric) | 69 cm |
| Display number of colours | 1.07 billion colours |
| Display resolution | 3840 x 2160 pixels |
| Display technology | LED |
| HD type | Quad HD |
| LED backlight | Yes |
| Maximum refresh rate | 60 Hz |
| Native aspect ratio | 16:9 |
| NTSC coverage (typical) | 85 % |
| Panel type | IPS |
| Response time | 5 ms |
| Screen shape | Flat |
| sRGB coverage (typical) | 100 % |
| Touchscreen | No |
| Viewing angle, horizontal | 178 ° |
| Viewing angle, vertical | 178 ° |
Multimedia
| Built-in camera | No |
| Built-in speaker(s) | No |
Design
| Detachable stand | Yes |
| Feet colour | Black |
| Front bezel colour | Black |
| Market positioning | Business |
| Product colour | Black |
Ports & interfaces
| Built-in USB hub | Yes |
| DisplayPort version | 1.4 |
| DisplayPorts quantity | 1 |
| HDMI | Yes |
| HDMI ports quantity | 1 |
| HDMI version | 2.0 |
| Headphone out | No |
| Number of USB Type-B upstream ports quantity | 1 |
| Number of USB Type-C upstream ports quantity | 1 |
| USB Power Delivery (USB PD) | Yes |
| USB Power Delivery up to | 65 W |
| USB Type-A downstream ports quantity | 2 |
Ergonomics
| Adjustable height (max) | 130 mm |
| Height adjustment | Yes |
| Panel mounting interface | 100 x 100 mm |
| Pivot | Yes |
| Pivot angle | -90 - 90 ° |
| Plug and Play | Yes |
| Swivel angle range | -30 - 30 ° |
| Swivelling | Yes |
| Tilt adjustment | Yes |
| Tilt angle range | 3 - 21 ° |
| VESA mounting | Yes |
| Wall mountable | Yes |
Power
| AC adapter output voltage | 12 V |
| Current rating | 5 A |
| Energy consumption (HDR) per 1000 hours | 25 kWh |
| Energy consumption (SDR) per 1000 hours | 25 kWh |
| Energy efficiency class (HDR) | F |
| Energy efficiency class (SDR) | F |
| Power consumption (off) | 0.3 W |
| Power consumption (standby) | 0.5 W |
| Power consumption (typical) | 60 W |
| Power supply type | External |
Operational conditions
| Operating relative humidity (H-H) | 10 - 85 % |
| Operating temperature (T-T) | 0 - 40 °C |
Weight & dimensions
| Depth (without stand) | 200 mm |
| Height (without stand) | 540.7 mm |
| Weight (without stand) | 5400 g |
| Width (without stand) | 613.7 mm |
Packaging data
| Package depth | 193 mm |
| Package height | 481 mm |
| Package type | Box |
| Package weight | 7600 g |
| Package width | 698 mm |
Packaging content
| Cables included | HDMI/USB Type-C |
| Manual | Yes |
| Power adapter included | Yes |
| Stand included | Yes |
Other features
| Compliance certificates | CE |
Energy Efficiency
| Data Sheet (Link) | https://eprel.ec.europa.eu/api/product/1815215/fiches?language=EN |
| Energy efficiency class | F |
| EPREL Registration Number | 1815215 |
| EPREL Version Number | 2 |
