- The 3440 × 1440 resolution produces clearer and more vivid pictures
- Comfortable 1500R exquisite curvature, close to the natural look and feel of the human eye, bringing immersive visual enjoyment
- Wide color gamut, 120% sRGB, 85% NTSC, 85% DCI-P3, 85% Adobe RGB. It meets the designer's demand of image texture
- Adaptive sync can effectively solve picture lagging and tearing problems
- 1ms Fast response time with no image blurring or ghosting
General
| Unit Calculated Weight | 9.3 kg |
| Product Net Weight | 7.3 kg |
| Unit Calculated Volume | 0.1046 cubm |
| Units per Pallet | 0 |
| Summary | Dahua Technology LM34-E330CA. Display diagonal: 86.4 cm (34"), Display resolution: 3440 x 1440 pixels, HD type: UltraWide Quad HD, Display technology: LCD, Response time: 1 ms, Native aspect ratio: 21:9, Viewing angle, horizontal: 178°, Viewing angle, vertical: 178°. VESA mounting, Height adjustment. Product colour: Black |
| Unit Box Height | 0.465 |
| Unit Box Length | 1.125 |
| Unit Box Width | 0.2 |
| Model name | LM34-E330CA |
| Model | DHI-LM34-E330CA |
Display
| Adobe RGB coverage | 85 % |
| Backlight type | Edge LED |
| Colour depth | 8 bit |
| Contrast ratio (typical) | 3500:1 |
| DCI-P3 coverage | 85 % |
| Display brightness (typical) | 300 cd/m² |
| Display diagonal | 34 " |
| Display resolution | 3440 x 1440 pixels |
| Display technology | LCD |
| Haze rate | 25 % |
| HD type | UltraWide Quad HD |
| High Dynamic Range (HDR) supported | Yes |
| High Dynamic Range (HDR) technology | High Dynamic Range 10 (HDR10) |
| Maximum refresh rate | 200 Hz |
| Native aspect ratio | 21:9 |
| NTSC coverage (typical) | 85 % |
| Panel type | VA |
| Pixel density | 109.7 ppi |
| Pixel pitch | 0.2318 x 0.2318 mm |
| Response time | 1 ms |
| Response time (MPRT) | 1 ms |
| Screen curvature rating | 1500R |
| Screen shape | Curved |
| sRGB coverage (typical) | 120 % |
| Touchscreen | No |
| Viewable size, horizontal | 797.22 mm |
| Viewable size, vertical | 333.72 mm |
| Viewing angle, horizontal | 178 ° |
| Viewing angle, vertical | 178 ° |
Performance
| Flicker-free technology | Yes |
| Low Blue Light technology | Yes |
Multimedia
| Built-in camera | No |
| Built-in speaker(s) | No |
Design
| Market positioning | Gaming |
| Product colour | Black |
Ports & interfaces
| Built-in USB hub | No |
| DisplayPort version | 1.4 |
| DisplayPorts quantity | 2 |
| HDMI | Yes |
| HDMI ports quantity | 2 |
| HDMI version | 2.0 |
| Headphone out | Yes |
Ergonomics
| Adjustable height (max) | 100 mm |
| Height adjustment | Yes |
| Panel mounting interface | 100 x 100 mm |
| Swivel angle range | -35 - 35 ° |
| Swivelling | Yes |
| Tilt adjustment | Yes |
| Tilt angle range | -5 - 15 ° |
| VESA mounting | Yes |
Power
| AC adapter output voltage | 19 V |
| Energy consumption (HDR) per 1000 hours | 43 kWh |
| Energy consumption (SDR) per 1000 hours | 30 kWh |
| Energy efficiency class (HDR) | Not available |
| Energy efficiency class (SDR) | F |
| Energy efficiency scale | A to G |
| Input current | 3.42 A |
| Power consumption (max) | 70 W |
| Power consumption (off) | 0.3 W |
| Power consumption (standby) | 0.5 W |
| Power consumption (typical) | 47 W |
| Power supply type | External |
Operational conditions
| Operating relative humidity (H-H) | 10 - 85 % |
| Operating temperature (T-T) | 0 - 40 °C |
| Storage relative humidity (H-H) | 5 - 90 % |
| Storage temperature (T-T) | -20 - 60 °C |
Weight & dimensions
| Depth (without stand) | 132.1 mm |
| Height (without stand) | 361.5 mm |
| Weight (without stand) | 7300 g |
| Width (without stand) | 810 mm |
Packaging data
| Package depth | 193 mm |
| Package height | 1468 mm |
| Package weight | 10200 g |
| Package width | 21124 mm |
Energy Efficiency
| Data Sheet (Link) | https://eprel.ec.europa.eu/api/product/1716135/fiches?language=EN |
| Energy efficiency class | F |
| EPREL Registration Number | 1716135 |
| EPREL Version Number | 1 |
