Driven by industry-leading technology, Dahua Wireless Series network cameras are highly precise and easy to install, producing high-quality images. They have strong wireless connection capabilities and do not require network cables, eliminating the need for a professional construction team. This series of cost-effective cameras supports local storage and is dustproof and waterproof. It is ideal for small and medium-sized scenes such as retail stores, homes, and other small and medium-sized enterprises.
General
| Unit Calculated Weight | 0.655 kg |
| Unit Calculated Volume | 0.003798 cubm |
| Units per Shipping Box | 20 |
| Units per Pallet | 0 |
| Summary | Dahua Technology F5D-PV-0280B. Type: IP security camera, Placement supported: Outdoor, Connectivity technology: Wireless. Mounting type: Wall, Product colour: White, Form factor: Bullet. Minimum illumination: 0.007 lx, Angle of rotation: 360°, Lens viewing angle, horizontal: 104°. Sensor type: CMOS, Optical sensor size: 25.4 / 2.7 mm (1 / 2.7"). Fixed focal length: 2.8 mm |
| Unit Box Height | 0.115 |
| Unit Box Length | 0.245 |
| Unit Box Width | 0.12 |
| Model | F5D-PV-0280B |
Performance
| Connectivity technology | Wireless |
| Day/night mode | Yes |
| Placement supported | Outdoor |
| Type | IP security camera |
| Wide Dynamic Range (WDR) | Yes |
Design
| Form factor | Bullet |
| Housing material | Metal/Plastic |
| International Protection (IP) code | IP67 |
| Mounting type | Wall |
| Product colour | White |
Camera
| Angle of rotation | 360 ° |
| Camera tilt control | Yes |
| Lens viewing angle, diagonal | 124 ° |
| Lens viewing angle, horizontal | 104 ° |
| Lens viewing angle, vertical | 56 ° |
| Minimum illumination | 0.007 lx |
| Tilt angle range | 0 - 90 ° |
Image sensor
| Optical sensor size | 1/2.7 " |
| Sensor type | CMOS |
Lens system
| Fixed focal length | 2.8 mm |
| Fixed focus | Yes |
| Maximum aperture number | 1.6 |
Night vision
| LED type | IR |
| Night vision | Yes |
| Night vision distance | 30 m |
| Number of illumination LEDs | 2 |
Video
| Digital Wide Dynamic Range (DWDR) | Yes |
| Frame rate | 30 fps |
| Maximum resolution | 2880 x 1620 pixels |
| Total megapixels | 5 MP |
| Video compression formats | H.264/H.264B/H.264H/H.265 |
| Video recording | Yes |
| Video streaming | Yes |
Audio
| Audio formats supported | G.711 µ-law/G.711 A-law/PCM |
| Built-in microphone | Yes |
| Built-in speaker(s) | Yes |
Network
| Bluetooth | Yes |
| Ethernet interface type | Fast Ethernet |
| Ethernet LAN | Yes |
| Wi-Fi | Yes |
| Wi-Fi standards | 802.11b/802.11g/Wi-Fi 4 (802.11n)/Wi-Fi 6 (802.11ax) |
Storage
| Built-in HDD | No |
| Card reader integrated | Yes |
| Compatible memory cards | MicroSD (TransFlash) |
| Maximum memory card size | 256 GB |
Ports & interfaces
| DC-in jack | Yes |
| Ethernet LAN (RJ-45) ports | 1 |
Security
| Human and vehicle targets classification | Yes |
| Video motion detection | Yes |
Management features
| Reset button | Yes |
Power
| DC output voltage | 12 |
| Power consumption (max) | 7.5 W |
| Power consumption (typical) | 2.4 W |
| Power source type | DC |
Operational conditions
| Operating temperature (T-T) | -40 - 60 °C |
System requirements
| Mobile operating systems supported | Android/iOS |
Weight & dimensions
| Diameter | 76.8 mm |
| Length | 158.3 mm |
| Weight | 340 g |
Sustainability
| Compliance certificates | CE |
Packaging content
| Manual | Yes |
| Number of cameras | 1 |
