The Neomounts desk mount, model FPMA-D510BLACK is a tilt-, swivel and rotatable desk mount for flat screens up to 32". This mount is a great choice for space saving placement on desks using a desk clamp or grommet mount.
Neomounts versatile tilt (90°), rotate (360°) and swivel (180°) technology allows the mount to change to any viewing angle to fully benefit from the capabilities of the flat screen. Cable management conceals and routes cables from mount to flat screen. Hide your cables to keep the workplace nice and tidy.
Neomounts FPMA-D510BLACK has one pivot points and is suitable for screens up to 32". The weight capacity of this product is 8 kg. The desk mount is suitable for screens that meet VESA hole pattern 75x75 or 100x100mm. Different hole patterns can be covered using Neomounts VESA adapter plates.
By using an ergonomic mount neck- and back complaints can be avoided. Ideal for use in offices and on counters or in a reception area.
All installation material is included with the product.
General
| Unit Calculated Weight | 3 kg |
| Unit Calculated Volume | 0.0066 cubm |
| Units per Shipping Box | 1 |
| Summary | Neomounts FPMA-D510BLACK Monitor arm 10-32". Mounting: Clamp/Grommet, Maximum weight capacity: 8 kg, Minimum screen size: 25.4 cm (10"), Maximum screen size: 81.3 cm (32"), Minimum VESA mount: 75 x 75 mm, Maximum VESA mount: 100 x 100 mm. Height adjustment, Swivel angle range: 0 - 180°, Tilt angle range: 0 - 90°. Product colour: Black |
| Unit Box Height | 0.12 |
| Unit Box Length | 0.5 |
| Unit Box Width | 0.11 |
Mounting
| Desk thickness (max) | 75 mm |
| Maximum screen size | 32 " |
| Maximum VESA mount | 100 x 100 mm |
| Maximum weight capacity | 8 kg |
| Maximum weight capacity (per display) | 8 kg |
| Minimum screen size | 10 " |
| Minimum VESA mount | 75 x 75 mm |
| Mounting | Clamp/Grommet |
| Mounting type | Desk |
| Number of displays supported | 1 |
| Panel mounting interface | 100 x 100/75 x 75 mm |
Ergonomics
| Angle of rotation | 360 ° |
| Cable management | Yes |
| Depth adjustment range | 0 - 88 mm |
| Height adjustment | Yes |
| Height adjustment range | 0 - 425 mm |
| Height adjustment type | Manual |
| Rotating | Yes |
| Swivel angle | 180 ° |
| Swivel angle range | 0 - 180 ° |
| Swivelling | Yes |
| Tilt adjustment | Yes |
| Tilt angle range | 0 - 90 ° |
Design
| Housing material | Steel |
| Product colour | Black |
Weight & dimensions
| Depth | 88 mm |
| Height | 425 mm |
| Weight | 2780 g |
Packaging data
| Package depth | 110 mm |
| Package height | 489 mm |
| Package net weight | 3300 g |
| Package weight | 3300 g |
| Package width | 120 mm |
Packaging content
| Clamp included | Yes |
| VESA mount included | Yes |
Logistics data
| Country of origin | China |
| Harmonized System (HS) code | 7326909890 |
| Master (outer) case gross weight | 19600 g |
| Master (outer) case height | 505 mm |
| Master (outer) case length | 350 mm |
| Master (outer) case net weight | 19600 g |
| Master (outer) case width | 260 mm |
| Products per master (outer) case | 6 pc(s) |
| Products per pallet (EU) | 144 pc(s) |
