Launched by Dahua Technology, WizSense is a series of AI products and solutions that adopt independent AI chip and deep learning algorithm. It focuses on human and vehicle with high accuracy, enabling users to fast act on defined targets. Based on Dahua's advanced technologies, WizSense provides intelligent, simple and inclusive products and solutions.
- High-Quality Imaging with 12MP Resolution
- Smart Dual Light: Built-in IR and LED Lights with 3 Illumination Modes Supported
- Deep Learning-Based Human and Vehicle Classification
- Built-in Mic for Real-Time Audio Security
- Supports Max. 256G Micro SD card
- Efficient H.264+/H.265+ Compression Technology
- Rich Interface: Alarm: 1 in, 1 out; audio: 1 in, 1 out
General
| Unit Calculated Weight | 1 kg |
| Unit Calculated Volume | 0.004104 cubm |
| Units per Shipping Box | 1 |
| Units per Pallet | 0 |
| Summary | Dahua Technology WizSense IPC-HFW21249T-AS-IL. Type: IP security camera, Placement supported: Indoor & outdoor, Connectivity technology: Wired. Mounting type: Ceiling/Wall/Pole, Product colour: White, Form factor: Bullet. Angle of rotation: 360°, Lens viewing angle, horizontal: 112°, Lens viewing angle, vertical: 58°. Sensor type: CMOS, Optical sensor size: 25.4 / 2.5 mm (1 / 2.5"). Signal-to-Noise Ratio (SNR) (panoramic camera): 56 dB |
| Unit Box Height | 0.12 |
| Unit Box Length | 0.285 |
| Unit Box Width | 0.12 |
Design
| Form factor | Bullet |
| Housing material | Metal |
| IK code | IK10 |
| International Protection (IP) code | IP67 |
| Mounting type | Ceiling/Wall/Pole |
| Product colour | White |
Performance
| Alarm input/output | Yes |
| Built-in light | Yes |
| Certification | CE-LVD: EN62368-1; CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU |
| Connectivity technology | Wired |
| Day/night mode | Yes |
| Placement supported | Indoor & outdoor |
| Type | IP security camera |
| Wide Dynamic Range (WDR) | Yes |
Camera
| Angle of rotation | 360 ° |
| Camera shutter speed | 1/3 - 1/100000 s |
| Camera shutter type | Electronic/Mechanical |
| Lens viewing angle, diagonal | 136 ° |
| Lens viewing angle, horizontal | 112 ° |
| Lens viewing angle, vertical | 58 ° |
| Minimum illumination | 0 lx |
| Number of Privacy masking areas | 4 |
| Pan range | 0 - 360 ° |
| Tilt angle range | 0 - 90 ° |
| White balance | Auto/Manual/Natural/Outdoor/Regional custom/Street lamp |
Image sensor
| Optical sensor size | 1/2.5 " |
| Progressive scan | Yes |
| Sensor type | CMOS |
Panoramic camera
| Signal-to-Noise Ratio (SNR) (panoramic camera) | 56 dB |
Lens system
| Closest focusing distance | 3.5 m |
| Detect distance | 98.9 m |
| Fixed focal length | 2.8 mm |
| Fixed focus | Yes |
| Identify distance | 9.9 m |
| Maximum aperture number | 1.6 |
| Number of lenses | 1 |
| Observe distance | 39.6 m |
| Recognize distance | 19.8 m |
Night vision
| LED type | IR/White |
| Night vision | Yes |
| Night vision distance | 30 m |
| Number of illumination LEDs | 4 |
Video
| Back Light Compensation (BLC) | Yes |
| Bit rate | H.264: 32 kbps-8192 kbps; H.265: 12 kbps-8192 kbps |
| Bit rate control | Constant Bit Rate (CBR)/Variable Bit Rate (VBR) |
| Digital Wide Dynamic Range (DWDR) | Yes |
| Gain control type | Auto/Manual |
| Highlight Compensation (HLC) | Yes |
| Maximum resolution | 4480 x 2512 pixels |
| Noise reduction | Yes |
| Noise reduction technology | 3D noise reduction |
| Privacy masking | Yes |
| Region of Interest (ROI) encoding | Yes |
| Supported graphics resolutions | 1280 x 960/2304 x 1296/2688 x 1520/2880 x 1620/3072 x 1728/3072 x 2048/352 x 240/352 x 288/3840 x 2160/704 x 480/704 x 576 |
| Supported video modes | 1080p/1296p/1520p/1536p/1620p/2160p/240p/2880p/480p/576p/720p/960p |
| Total megapixels | 12 MP |
| Video compression formats | H.264/H.264+/H.264B/H.264H/H.265/H.265+/M-JPEG |
| Video streaming | Yes |
Audio
| Audio input channels | 1.0 channels |
| Audio output channels | 1.0 channels |
| Built-in microphone | Yes |
| Number of microphones | 1 |
| Voice codecs | G.711a/G.711Mu/G.726/PCM |
Network
| Bluetooth | No |
| Client interoperability | ONVIF (Profile S & Profile G & Profile T); CGI |
| Ethernet interface type | Fast Ethernet |
| Ethernet LAN | Yes |
| Networking standards | IEEE 802.3af |
| Number of users | 20 user(s) |
| Supported network protocols | IPv4; IPv6; HTTP; TCP; UDP; ARP; RTP; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; PPPoE; P2P; Bonjour; Auto Registration |
| Wi-Fi | No |
Storage
| Built-in HDD | No |
| Card reader integrated | Yes |
| Compatible memory cards | MicroSD (TransFlash) |
| Maximum memory card size | 256 GB |
| RAM capacity | 512 MB |
| ROM capacity | 128 MB |
Ports & interfaces
| Ethernet LAN (RJ-45) ports | 1 |
Security
| Intelligent Video Surveillance (IVS) system features | Intrusion/Tripwire |
| Video motion detection | Yes |
Power
| DC output voltage | 12 |
| Power consumption (max) | 10.1 W |
| Power consumption (Power over Ethernet (PoE)) | 3.7 W |
| Power consumption (typical) | 3.1 W |
| Power source type | DC,PoE |
Operational conditions
| Operating relative humidity (H-H) | 0 - 95 % |
| Operating temperature (T-T) | -40 - 60 °C |
| Storage relative humidity (H-H) | 0 - 95 % |
| Storage temperature (T-T) | -40 - 60 °C |
System requirements
| Mobile operating systems supported | Android/iOS |
Weight & dimensions
| Height | 90.7 mm |
| Length | 238.5 mm |
| Weight | 720 g |
| Width | 90.7 mm |
Packaging data
| Package weight | 970 g |
Packaging content
| Number of cameras | 1 |
Technical details
| Audio input | RCA |
| Iris | Yes |
| Lens mount interface | M12 |
Other features
| Audio output | RCA |
| Browser supported | IE; Chrome; Firefox |
| Data transfer rate | 100 Mbit/s |
