Driven by industry-leading technology, Dahua Wireless Series network cameras are highly precise and easy to install, producing high-quality images. They have strong wireless connection capabilities and do not require network cables, eliminating the need for a professional construction team. This series of cost-effective cameras supports local storage and is dustproof and waterproof. It is ideal for small and medium-sized scenes such as retail stores, homes, and other small and medium-sized enterprises.
General
| Unit Calculated Weight | 2.68 kg |
| Unit Calculated Volume | 0.02279 cubm |
| Units per Shipping Box | 10 |
| Units per Pallet | 0 |
| Summary | Dahua Technology KIT/BP4A-4G-0360B/M0508. Type: IP security camera, Placement supported: Outdoor, Connectivity technology: Wireless. Mounting type: Wall, Product colour: White, Housing material: Plastic. Angle of rotation: 360°, Lens viewing angle, horizontal: 78.4°, Lens viewing angle, vertical: 42.4°. Sensor type: CMOS, Optical sensor size: 25.4 / 3 mm (1 / 3"). Fixed focal length: 3.6 mm |
| Unit Box Height | 0.181 |
| Unit Box Length | 0.392 |
| Unit Box Width | 0.267 |
| Model name | KIT/BP4A-4G-0360B/M0508 |
Performance
| Connectivity technology | Wireless |
| Day/night mode | Yes |
| Placement supported | Outdoor |
| Type | IP security camera |
| Wide Dynamic Range (WDR) | Yes |
Design
| Housing material | Plastic |
| International Protection (IP) code | IP66 |
| Mounting type | Wall |
| Product colour | White |
| Protection features | Dustproof/Waterproof |
Camera
| Angle of rotation | 360 ° |
| Camera pan control | Yes |
| Camera tilt control | Yes |
| Lens viewing angle, diagonal | 92.4 ° |
| Lens viewing angle, horizontal | 78.4 ° |
| Lens viewing angle, vertical | 42.4 ° |
| Pan range | 0 - 360 ° |
| Tilt angle range | -60 - 0 ° |
Image sensor
| Optical sensor size | 1/3 " |
| Sensor type | CMOS |
Lens system
| Fixed focal length | 3.6 mm |
| Maximum aperture number | 1.6 |
Night vision
| LED type | IR |
| Night vision | Yes |
| Night vision distance | 30 m |
Video
| Frame rate | 15 fps |
| Maximum resolution | 2560 x 1440 pixels |
| Total megapixels | 4 MP |
| Video compression formats | H.265 |
| Video streaming | Yes |
Audio
| Audio formats supported | G.711 A-law |
| Built-in microphone | Yes |
| Built-in speaker(s) | Yes |
Network
| 4G standard | LTE-FDD |
| Bluetooth | No |
| Ethernet interface type | Fast Ethernet |
| Ethernet LAN | Yes |
| Mobile network connection | Yes |
| Mobile network generation | 4G |
| Wi-Fi | No |
Storage
| Built-in HDD | No |
Ports & interfaces
| Ethernet LAN (RJ-45) ports | 1 |
| USB port | Yes |
Security
| Video motion detection | Yes |
Power
| Battery capacity | 68 Wh |
| Battery technology | Lithium |
| Power source type | USB,Solar |
Operational conditions
| Operating temperature (T-T) | -20 - 60 °C |
System requirements
| Mobile operating systems supported | Android/iOS |
Weight & dimensions
| Height | 360 mm |
| Length | 284 mm |
| Weight | 1055 g |
| Width | 172 mm |
Sustainability
| Compliance certificates | CE |
Packaging content
| Manual | Yes |
| Number of cameras | 1 |
