Highlights
| Product Highlights |
|
Processor
| Processor Manufacturer | Intel |
| Processor Family | Intel® Core™ i5 |
| Processor Generation | Intel® Core™ i5 (14th gen) |
| Processor Model | i5-14500 |
| Processor Cores | 14 |
| Processor Threads | 20 |
| Processor Boost Frequency | 5 GHz |
| Performance Cores | 6 |
| Efficient Cores | 8 |
| Performance-core Max Turbo Frequency | 5 GHz |
| Efficient-core Max Turbo Frequency | 3.7 GHz |
| Performance-core Base Frequency | 2.6 GHz |
| Efficient-core Base Frequency | 1.9 GHz |
| Processor Cache | 24 MB |
| Processor Cache Type | Smart Cache |
| Number of Processors Installed | 1 |
| Processor Base Power | 65 W |
| Maximum Turbo Power | 154 W |
Memory
| Internal Memory | 16 GB |
| Maximum Internal Memory | 32 GB |
| Internal Memory Type | DDR5-SDRAM |
| Memory Layout (slots X Size) | 1 x 16 GB |
| Memory Slots | 2x DIMM |
Storage
| Total Storage Capacity | 512 GB |
| Storage Media | SSD |
| Optical Drive Type | No |
| Total SSDs Capacity | 512 GB |
| Number of SSDs Installed | 1 |
| SSD Capacity | 512 GB |
Graphics
| Discrete Graphics Card | No |
| On-board Graphics Card | Yes |
| Discrete Graphics Card Model | Not available |
| On-board GPU Manufacturer | Intel |
| On-board Graphics Card Family | Intel® UHD Graphics |
| On-board Graphics Card Model | Intel UHD Graphics 770 |
Network
| Ethernet LAN | Yes |
| Wi-Fi | Yes |
Ports & Interfaces
| USB 2.0 Ports Quantity | 4 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A Ports Quantity | 3 |
| HDMI Ports Quantity | 1 |
| HDMI Version | 2.1 |
| DisplayPorts Quantity | 1 |
| Ethernet LAN (RJ-45) Ports | 1 |
| Combo Headphone/mic Port | Yes |
Design
| Chassis Type | Slim PC |
| Product Colour | Black |
Performance
| Motherboard Chipset | Intel Q670 |
| Audio Chip | Realtek ALC3204 |
| Trusted Platform Module (TPM) | Yes |
| Product Type | PC |
| Trusted Platform Module (TPM) Version | 2.0 |
Software
| Operating System Installed | Windows 11 Pro |
Operational Conditions
| Operating Temperature (T-T) | 10 - 35 °C |
| Operating Relative Humidity (H-H) | 20 - 80% |
Weight & Dimensions
| Width | 95 mm |
| Depth | 293 mm |
| Height | 303.5 mm |
Packaging Content
| Keyboard Included | No |
Display
| Display Included | No |
Warranty and Other
| Warranty Terms | 36 months |
| Product Condition | Original |
