Ubiquiti sets the bar for the world's first low-cost and efficient broadband Customer Premises Equipment (CPE) with the original NanoStation®. The NanoStationM and NanoStationlocoM take the same concept to the future with sleek and elegant form factors, along with integrated airMAX® (MIMO TDMA protocol) technology. The low cost, high performance, and small form factor of NanoStationM and NanoStationlocoM make them extremely versatile and economical to deploy.
- Versatile Mounting
- Improved Surge Protection
- Efficient Footprint
- Quick Installation
General
| Unit Calculated Weight | 0.57 kg |
| Unit Calculated Volume | 0.002144 cubm |
| Units per Shipping Box | 20 |
| Summary | Ubiquiti LocoM2. Maximum data transfer rate: 150 Mbit/s. Antenna design: Internal, Antenna gain level (max): 8.5 dBi. Wi-Fi band: Single-band (2.4 GHz), Frequency band: 2.412 - 2.462 GHz. Ethernet LAN interface type: Fast Ethernet, Ethernet LAN data rates: 10,100 Mbit/s, Cabling technology: 10/100Base-T(X). Connectivity technology: Wired & Wireless |
| Unit Box Height | 0.25 |
| Unit Box Length | 0.49 |
| Unit Box Width | 0.0175 |
Data transmission
| Maximum data transfer rate | 150 Mbit/s |
Antenna
| Antenna design | Internal |
| Antenna gain level (max) | 8.5 dBi |
Wireless LAN features
| Frequency band | 2.412 - 2.462 GHz |
| Wi-Fi | Yes |
| Wi-Fi band | Single-band (2.4 GHz) |
Network
| Cabling technology | 10/100Base-T(X) |
| Ethernet LAN | Yes |
| Ethernet LAN data rates | 10/100 Mbit/s |
| Ethernet LAN interface type | Fast Ethernet |
Ports & interfaces
| Connectivity technology | Wired & Wireless |
| Ethernet LAN (RJ-45) ports | 1 |
Features
| Internal memory | 32 MB |
| Material | Plastic |
| Mounting type | Pole |
| Processor family | Atheros |
| Processor frequency | 400 MHz |
| Processor model | MIPS 24Kc |
| Product colour | White |
| Product type | Network bridge |
| RAM type | SDRAM |
Power
| Power consumption (max) | 5.5 W |
| Power over Ethernet (PoE) | Yes |
| Power over Ethernet (PoE) voltage | 24 V |
Operational conditions
| Operating relative humidity (H-H) | 5 - 95 % |
| Operating temperature (T-T) | -30 - 75 °C |
Certificates
| Certification | FCC 15.247, IC RS210, CE, RoHS |
Weight & dimensions
| Depth | 31 mm |
| Height | 161 mm |
| Weight | 180 g |
| Width | 80 mm |
Memory
| Flash memory | 8 MB |
Logistics data
| Harmonized System (HS) code | 85176990 |
