SAMSUNG 27 " 5120 x 2880 pixels 5K Ultra HD Native aspect ratio 16:9 LCD Flat LS27HG806EFXEN
General
| Unit Calculated Weight | 8.6 kg |
| Product Net Weight | 6.2 kg |
| Unit Calculated Volume | 0.04738 cubm |
| Units per Pallet | 0 |
| Summary | Samsung G80HF. Display diagonal: 68.6 cm (27"), Display resolution: 5120 x 2880 pixels, HD type: 5K Ultra HD, Display technology: LCD, Response time: 1 ms, Native aspect ratio: 16:9, Viewing angle, horizontal: 178°, Viewing angle, vertical: 178°. Built-in USB hub, USB hub version: 3.2 Gen 1 (3.1 Gen 1). VESA mounting, Height adjustment. Product colour: Black |
| Unit Box Height | 0.15 |
| Unit Box Length | 0.665 |
| Unit Box Width | 0.475 |
| Model name | G80HF |
Display
| Contrast ratio (typical) | 1000:1 |
| Display brightness (min) | 250 cd/m² |
| Display brightness (peak) | 350 cd/m² |
| Display brightness (typical) | 400 cd/m² |
| Display diagonal | 27 " |
| Display diagonal (metric) | 68 cm |
| Display number of colours | 1 billion colours |
| Display resolution | 5120 x 2880 pixels |
| Display technology | LCD |
| HD type | 5K Ultra HD |
| High Dynamic Range (HDR) supported | Yes |
| High Dynamic Range (HDR) technology | High Dynamic Range 10+ Gaming (HDR10 Plus Gaming) |
| Maximum refresh rate | 360 Hz |
| Native aspect ratio | 16:9 |
| Panel type | IPS |
| Response time | 1 ms |
| Response time measurement type | GTG (Gray to Gray) |
| Screen shape | Flat |
| sRGB coverage (typical) | 99 % |
| Touchscreen | No |
| Viewable size, horizontal | 595.968 mm |
| Viewable size, vertical | 335.232 mm |
| Viewing angle, horizontal | 178 ° |
| Viewing angle, vertical | 178 ° |
Performance
| AMD FreeSync | Yes |
| AMD FreeSync type | FreeSync Premium |
| Flicker-free technology | Yes |
| Game features | Super Arena Gaming UX |
| NVIDIA G-SYNC | Yes |
| NVIDIA G-SYNC type | G-SYNC Compatible |
Multimedia
| Built-in camera | No |
| Built-in speaker(s) | No |
Design
| Feet colour | Black |
| Market positioning | Gaming |
| Product colour | Black |
Ports & interfaces
| Built-in USB hub | Yes |
| DisplayPorts quantity | 1 |
| HDCP | Yes |
| HDCP version | 2.2 |
| HDMI | Yes |
| HDMI ports quantity | 2 |
| HDMI version | 2.1 |
| Headphone out | Yes |
| Headphone outputs | 1 |
| Number of USB Type-B upstream ports quantity | 1 |
| USB hub version | 3.2 Gen 1 (3.1 Gen 1) |
| USB Type-A downstream ports quantity | 2 |
Ergonomics
| Adjustable height (max) | 120 mm |
| Black eQualizer function | Yes |
| Height adjustment | Yes |
| Panel mounting interface | 100 x 100 mm |
| Pivot | Yes |
| Pivot angle | -92 - 92 ° |
| Swivel angle range | -30 - 30 ° |
| Swivelling | Yes |
| Tilt adjustment | Yes |
| Tilt angle range | -2 - 25 ° |
| VESA mounting | Yes |
Power
| AC input frequency | 50/60 Hz |
| AC input voltage | 100 - 240 V |
| Energy consumption (HDR) per 1000 hours | 61 kWh |
| Energy consumption (SDR) per 1000 hours | 26 kWh |
| Energy efficiency class (HDR) | G |
| Energy efficiency class (SDR) | F |
| Energy efficiency scale | A to G |
| Power consumption (max) | 78 W |
| Power consumption (standby) | 0.5 W |
| Power consumption (typical) | 26 W |
| Power supply type | External |
Operational conditions
| Operating relative humidity (H-H) | 10 - 80 % |
| Operating temperature (T-T) | 10 - 40 °C |
Weight & dimensions
| Depth (with stand) | 263.9 mm |
| Depth (without stand) | 59.6 mm |
| Height (with stand) | 566.6 mm |
| Height (without stand) | 365.1 mm |
| Weight (with stand) | 6200 g |
| Weight (without stand) | 3700 g |
| Width (with stand) | 614.1 mm |
| Width (without stand) | 614.1 mm |
Packaging data
| Package depth | 153 mm |
| Package height | 477 mm |
| Package weight | 8300 g |
| Package width | 665 mm |
| Stand type | HAS stand |
Packaging content
| Cables included | DisplayPort/HDMI/Power/USB Type-A to USB Type-B |
| Power cable length | 1.5 m |
| Stand included | Yes |
Other features
| Auto source switch+ | Yes |
| Image size | Yes |
| Off Timer Plus | Yes |
| Samsung Eye Saver Mode | Yes |
| Virtual AIM point | Yes |
Energy Efficiency
| Data Sheet (Link) | https://eprel.ec.europa.eu/api/product/2623694/fiches?language=EN |
| Energy efficiency class | F |
| EPREL Registration Number | 2623694 |
| EPREL Version Number | 1 |
