SAMSUNG 40 " 5120 x 2160 pixels WUHD Native aspect ratio 21:9 LCD Curved LS40H850TAUXEN
General
| Unit Calculated Weight | 14 kg |
| Unit Calculated Volume | 0.1473 cubm |
| Units per Pallet | 0 |
| Summary | Samsung S85TH. Display diagonal: 101.6 cm (40"), Display resolution: 5120 x 2160 pixels, HD type: WUHD, Display technology: LCD, Response time: 4 ms, Native aspect ratio: 21:9, Viewing angle, horizontal: 178°, Viewing angle, vertical: 178°. Built-in speaker(s). Built-in USB hub, USB hub version: 3.2 Gen 2 (3.1 Gen 2). VESA mounting, Height adjustment. Product colour: Black |
| Unit Box Height | 0.275 |
| Unit Box Length | 1.03 |
| Unit Box Width | 0.52 |
| Model name | S85TH |
Display
| Contrast ratio (typical) | 3000:1 |
| Display brightness (min) | 280 cd/m² |
| Display brightness (typical) | 350 cd/m² |
| Display diagonal | 40 " |
| Display diagonal (metric) | 100 cm |
| Display number of colours | 1.07 billion colours |
| Display resolution | 5120 x 2160 pixels |
| Display technology | LCD |
| HD type | WUHD |
| High Dynamic Range (HDR) supported | Yes |
| High Dynamic Range (HDR) technology | High Dynamic Range 10 (HDR10)/High Dynamic Range 10+ (HDR10 Plus) |
| Maximum refresh rate | 144 Hz |
| Native aspect ratio | 21:9 |
| Panel type | VA |
| Response time | 4 ms |
| Response time measurement type | GTG (Gray to Gray) |
| Screen curvature rating | 1000R |
| Screen shape | Curved |
| sRGB coverage (typical) | 99 % |
| Touchscreen | No |
| Viewable size, horizontal | 926.8 mm |
| Viewable size, vertical | 391 mm |
| Viewing angle, horizontal | 178 ° |
| Viewing angle, vertical | 178 ° |
Performance
| AMD FreeSync | Yes |
| AMD FreeSync type | FreeSync Premium |
| Flicker-free technology | Yes |
| NVIDIA G-SYNC | No |
Multimedia
| Built-in camera | No |
| Built-in speaker(s) | Yes |
| RMS rated power | 5 W |
Design
| Feet colour | Black |
| Market positioning | Home |
| Product colour | Black |
Ports & interfaces
| Built-in KVM switch | Yes |
| Built-in USB hub | Yes |
| DisplayPort out version | 1.4 |
| DisplayPorts quantity | 1 |
| HDMI | Yes |
| HDMI ports quantity | 1 |
| HDMI version | 2.1 |
| Headphone out | Yes |
| Headphone outputs | 1 |
| Number of USB Type-C upstream ports quantity | 1 |
| Thunderbolt ports quantity | 1 |
| USB hub version | 3.2 Gen 2 (3.1 Gen 2) |
| USB Power Delivery (USB PD) | Yes |
| USB Power Delivery up to | 140 W |
| USB Type-A downstream ports quantity | 5 |
| USB Type-C downstream ports quantity | 1 |
Network
| Ethernet LAN | Yes |
Ergonomics
| Adjustable height (max) | 120 mm |
| Height adjustment | Yes |
| Panel mounting interface | 100 x 100 mm |
| Picture-in-Picture | Yes |
| Swivel angle range | -20 - 20 ° |
| Swivelling | Yes |
| Tilt adjustment | Yes |
| Tilt angle range | -5 - 20 ° |
| VESA mounting | Yes |
Power
| AC input frequency | 50/60 Hz |
| AC input voltage | 100 - 240 V |
| Energy consumption (HDR) per 1000 hours | 120 kWh |
| Energy consumption (SDR) per 1000 hours | 42 kWh |
| Energy efficiency class (HDR) | G |
| Energy efficiency class (SDR) | G |
| Energy efficiency scale | A to G |
| Power consumption (max) | 340 W |
| Power consumption (standby) | 0.5 W |
| Power consumption (typical) | 42 W |
| Power supply type | Internal |
Operational conditions
| Operating relative humidity (H-H) | 10 - 80 % |
| Operating temperature (T-T) | 10 - 40 °C |
Weight & dimensions
| Depth (with stand) | 362.1 mm |
| Depth (without stand) | 198.9 mm |
| Height (with stand) | 599.9 mm |
| Height (without stand) | 422.8 mm |
| Weight (with stand) | 14000 g |
| Weight (without stand) | 9000 g |
| Width (with stand) | 928.6 mm |
| Width (without stand) | 928.6 mm |
Packaging data
| Package depth | 281 mm |
| Package height | 520 mm |
| Package weight | 17500 g |
| Package width | 1030 mm |
| Stand type | HAS stand |
Packaging content
| Cables included | HDMI/Power |
| Power cable length | 1.5 m |
| Stand included | Yes |
Other features
| Adaptive picture | Yes |
| Auto source switch+ | Yes |
| Factory tunning | Yes |
| Off Timer Plus | Yes |
| Picture-by-Picture (PbP) | Yes |
| RJ-45 ports quantity | 1 |
| Samsung Eye Saver Mode | Yes |
Energy Efficiency
| Data Sheet (Link) | https://eprel.ec.europa.eu/api/product/2633345/fiches?language=EN |
| Energy efficiency class | G |
| EPREL Registration Number | 2633345 |
| EPREL Version Number | 2 |
