Monitor wall mount with single monitor arm
Arm rotates, extends and retracts, tilts to change reading angles, and allows to rotate display from landscape-to-portrait mode, etc
Enables easy ergonomic positioning for reduced strain
Works with almost any LCD monitor (max. 27'')
Durable adjustable spring suitable for monitors of 2 - 7 kg
Built-in cable management for an organized and neat workspace
VESA compatible (100 x 100 mm and 75 x 75 mm)
- Position your screen perfectly
General
| Unit Calculated Weight | 2.3 kg |
| Unit Calculated Volume | 0.0104 cubm |
| Units per Shipping Box | 4 |
| Summary | Gembird MA-WA1-02. Maximum weight capacity: 7 kg, Minimum screen size: 43.2 cm (17"), Maximum screen size: 68.6 cm (27"), Minimum VESA mount: 75 x 75 mm, Maximum VESA mount: 100 x 100 mm. Height adjustment, Swivel angle range: -90 - 90°, Tilt angle range: -45 - 90°. Product colour: Black |
| CnCode | 83021000 |
| Unit Box Height | 0.085 |
| Unit Box Length | 0.39 |
| Unit Box Width | 0.25 |
| Model | MA-WA1-02 |
Mounting
| Maximum screen size | 27 " |
| Maximum VESA mount | 100 x 100 mm |
| Maximum weight capacity | 7 kg |
| Maximum weight capacity (per display) | 7 kg |
| Minimum screen size | 17 " |
| Minimum VESA mount | 75 x 75 mm |
| Mounting type | Wall |
| Number of displays supported | 1 |
| Panel mounting interface | 100 x 100/75 x 75 mm |
Ergonomics
| Angle of rotation | 180 ° |
| Cable management | Yes |
| Height adjustment | Yes |
| Height adjustment type | Manual |
| Number of arms | 1 |
| Rotating | Yes |
| Swivel angle range | -90 - 90 ° |
| Swivelling | Yes |
| Tilt adjustment | Yes |
| Tilt angle range | -45 - 90 ° |
Design
| Easy to install | Yes |
| Housing material | Aluminium/Plastic/Steel |
| Orientation | Landscape/Portrait |
| Product colour | Black |
Weight & dimensions
| Depth | 532 mm |
| Height | 117 mm |
| Weight | 1710 g |
| Width | 497 mm |
Packaging data
| Package depth | 385 mm |
| Package height | 90 mm |
| Package type | Box |
| Package weight | 2302 g |
| Package width | 245 mm |
| Quantity per pack | 1 pc(s) |
Packaging content
| Manual | Yes |
| Mounting kit | Yes |
Other features
| Compliance certificates | RoHS |
Logistics data
| Country of origin | China |
