Experience immersive gaming with the MAG 274QPF E20 gaming monitor. It features a 2560 x 1440 (WQHD) panel, a 200Hz refresh rate, and a rapid 0.5ms (GtG, Min) response time. The monitor is VESA DisplayHDR 400, enhancing eye-catching details through adjustments in contrast and shadows. Designed for competitive FPS, first-person RPG/MMORPG, and flight/racing simulator genres, the MSI MAG 274QPF E20 gaming monitor takes casual gaming to a new level, challenging players to see beyond the game.
MSI's mainstream MAG series epitomizes stability and durability and is built to withstand the most intense gaming sessions. The entire lineup features robust construction with metallic-like hardness and excellent heat dissipation, ensuring stability for all critical gaming components.
- Rapid IPS Panel – Provides 0.5ms (GtG, Min.) response time, optimizes screen colors and brightness
- 200Hz Refresh Rate – Respond faster with smoother frames
- 0.5ms (GtG, Min.) Response Time – Eliminate screen tearing and choppy frame rates
- AI Vision – The new AI Vision technology can not only reveal details in dark areas but also enhance overall brightness and saturate colors
- Less Blue Light – Use a software solution to reduce the light emission in the blue-violet region of the blue light spectrum
General
| Unit Calculated Weight | 9.4 kg |
| Product Net Weight | 6.8 kg |
| Unit Calculated Volume | 0.05377 cubm |
| Units per Pallet | 0 |
| Summary | MSI MAG 274QPF E20. Display diagonal: 68.6 cm (27"), Display resolution: 2560 x 1440 pixels, HD type: Wide Quad HD, Display technology: LCD, Response time: 0.5 ms, Native aspect ratio: 16:9, Viewing angle, horizontal: 178°, Viewing angle, vertical: 178°. VESA mounting. Product colour: Black |
| Unit Box Height | 0.46 |
| Unit Box Length | 0.835 |
| Unit Box Width | 0.14 |
| Model name | MAG 274QPF E20 |
Display
| Adobe RGB coverage | 92 % |
| Anti-glare screen | Yes |
| Colour depth | 8 bit |
| Colour gamut | 95 % |
| Colour gamut standard | DCI-P3 |
| Contrast ratio (dynamic) | 100000000:1 |
| Contrast ratio (typical) | 1000:1 |
| DCI-P3 coverage | 95 % |
| Display brightness (peak) | 300 cd/m² |
| Display diagonal | 27 " |
| Display number of colours | 1.07 billion colours |
| Display resolution | 2560 x 1440 pixels |
| Display technology | LCD |
| HD type | Wide Quad HD |
| High Dynamic Range (HDR) supported | Yes |
| High Dynamic Range (HDR) technology | DisplayHDR 400 |
| Horizontal scan range | 72 - 300 kHz |
| Maximum refresh rate | 200 Hz |
| Native aspect ratio | 16:9 |
| Panel type | Rapid IPS |
| Pixel pitch | 0.2331 x 0.2331 mm |
| Response time | 0.5 ms |
| Response time measurement type | GTG (Gray to Gray) |
| Screen shape | Flat |
| sRGB coverage (typical) | 124 % |
| Touchscreen | No |
| Vertical scan range | 48 - 200 Hz |
| Viewable size, horizontal | 596.736 mm |
| Viewable size, vertical | 335.664 mm |
| Viewing angle, horizontal | 178 ° |
| Viewing angle, vertical | 178 ° |
Performance
| AMD FreeSync | Yes |
| AMD FreeSync type | FreeSync Premium |
| Flicker-free technology | Yes |
| Low Blue Light technology | Yes |
| NVIDIA G-SYNC | No |
Multimedia
| Built-in camera | No |
| Built-in speaker(s) | No |
Design
| Frameless design | Yes |
| Market positioning | Gaming |
| Product colour | Black |
Ports & interfaces
| Audio input | No |
| Built-in USB hub | No |
| DisplayPort version | 1.4a |
| DisplayPorts quantity | 1 |
| DVI port | No |
| HDMI | Yes |
| HDMI ports quantity | 2 |
| HDMI version | 2.0b |
| Headphone out | Yes |
| Headphone outputs | 1 |
Ergonomics
| Adjustable height (max) | 130 mm |
| Cable lock slot | Yes |
| Cable lock slot type | Kensington |
| Height adjustment | No |
| Panel mounting interface | 100 x 100 mm |
| Pivot | No |
| Pivot angle | -90 - 90 ° |
| Swivel angle range | -30 - 30 ° |
| Swivelling | No |
| Tilt adjustment | Yes |
| Tilt angle range | -5 - 20 ° |
| VESA mounting | Yes |
Power
| AC input frequency | 50/60 Hz |
| AC input voltage | 100 - 240 V |
| Energy consumption (HDR) per 1000 hours | 40 kWh |
| Energy consumption (SDR) per 1000 hours | 21 kWh |
| Energy efficiency class (HDR) | G |
| Energy efficiency class (SDR) | E |
| Power consumption (off) | 0.3 W |
| Power consumption (standby) | 0.5 W |
| Power supply type | Internal |
Weight & dimensions
| Depth (with stand) | 227.9 mm |
| Depth (without stand) | 57 mm |
| Height (with stand) | 404.8 mm |
| Height (without stand) | 365.4 mm |
| Weight (with stand) | 6800 g |
| Width (with stand) | 613.5 mm |
| Width (without stand) | 613.5 mm |
Packaging data
| Package type | Box |
| Package weight | 9200 g |
Packaging content
| Cables included | DisplayPort/Power |
| Quick start guide | Yes |
Energy Efficiency
| Data Sheet (Link) | https://eprel.ec.europa.eu/api/product/2402289/fiches?language=EN |
| Energy efficiency class | E |
| EPREL Registration Number | 2402289 |
| EPREL Version Number | 1 |
