Visualize your victory with the MAG 321UP QD-OLED gaming monitor. It boasts a 3840x2160 (UHD) next-gen QD-OLED panel, 165Hz refresh rate, and rapid 0.03ms (GtG) response time. VESA certification for ClearMR 9000 and DisplayHDR True Black 400 ensures exceptionally vivid images and mitigates motion blur. OLED Care 2.0 reduces OLED burn-in risks. For console gamers, the MAG 321UP QD-OLED provides HDMI™ 2.1 ports with 48Gbps bandwidth, 120Hz support, VRR, and ALLM.
- 3rd QD-OLED Panel – With stunning image quality and fast response time
- Fastest 0.03ms GtG response time and 165Hz refresh rate
- QD Premium Color – Ensures the color meets the market standard – Delta E≤2
- Incredible HDR visual – VESA DisplayHDR True Black 400
- MSI OLED Care 2.0 – Reduced the risk of OLED burn-in
- Console Mode – Provide HDMI™ 2.1 (4K@165Hz) with a full 48 Gbps bandwidth
- Adjustable Stand – Easily change the position of the monitor for maximum ergonomics
- 3-Year Burn-In Warranty – Including coverage for OLED burn-in
General
| Unit Calculated Weight | 11.8 kg |
| Product Net Weight | 9.1 kg |
| Unit Calculated Volume | 0.09337 cubm |
| Summary | MSI MAG 321UP QD-OLED. Display diagonal: 80 cm (31.5"), Display resolution: 3840 x 2160 pixels, HD type: 4K Ultra HD, Display technology: QD-OLED, Response time: 1 ms, Native aspect ratio: 16:9, Viewing angle, horizontal: 178°, Viewing angle, vertical: 178°. VESA mounting, Height adjustment. Product colour: Black |
| Unit Box Height | 0.515 |
| Unit Box Length | 0.98 |
| Unit Box Width | 0.185 |
| Model name | MAG 321UP QD-OLED |
| Model | MAG 321UP QD-OLED |
Display
| Anti-glare screen | Yes |
| Aspect ratio | 16:9 |
| Colour gamut | 110.1 % |
| Colour gamut standard | DCI-P3 |
| Contrast ratio (typical) | 1500000:1 |
| Display brightness (typical) | 250 cd/m² |
| Display diagonal | 31.5 " |
| Display number of colours | 1.07 billion colours |
| Display resolution | 3840 x 2160 pixels |
| Display technology | QD-OLED |
| HD type | 4K Ultra HD |
| Horizontal scan range | 30 - 390 kHz |
| Maximum refresh rate | 165 Hz |
| Native aspect ratio | 16:9 |
| Pixel pitch | 0.1814 x 0.1814 mm |
| Response time | 1 ms |
| Screen shape | Flat |
| sRGB coverage (typical) | 138.2 % |
| Touchscreen | No |
| Vertical scan range | 48 - 165 Hz |
| Viewable size, horizontal | 699.48 mm |
| Viewable size, vertical | 394.73 mm |
| Viewing angle, horizontal | 178 ° |
| Viewing angle, vertical | 178 ° |
Performance
| AMD FreeSync | No |
| NVIDIA G-SYNC | No |
Multimedia
| Built-in camera | No |
| Built-in speaker(s) | No |
Design
| Frameless design | Yes |
| Market positioning | Gaming |
| Product colour | Black |
Ports & interfaces
| Built-in USB hub | No |
| DisplayPort version | 1.4a |
| DisplayPorts quantity | 1 |
| HDMI | Yes |
| HDMI ports quantity | 2 |
| HDMI version | 2.1 |
| Headphone out | Yes |
| Headphone outputs | 1 |
| USB Type-C DisplayPort Alternate Mode | Yes |
| USB Type-C downstream ports quantity | 1 |
Ergonomics
| Adjustable height (max) | 110 mm |
| Cable lock slot | Yes |
| Cable lock slot type | Kensington |
| Height adjustment | Yes |
| Panel mounting interface | 100 x 100 mm |
| Pivot | Yes |
| Pivot angle | -10 - 10 ° |
| Swivel angle range | 30 - 30 ° |
| Swivelling | Yes |
| Tilt adjustment | Yes |
| Tilt angle range | -5 - 15 ° |
| VESA mounting | Yes |
Power
| AC input frequency | 50/60 Hz |
| AC input voltage | 100 - 240 V |
| Energy consumption (HDR) per 1000 hours | 50 kWh |
| Energy consumption (SDR) per 1000 hours | 33 kWh |
| Energy efficiency class (HDR) | G |
| Energy efficiency class (SDR) | G |
| Energy efficiency scale | A to G |
| Power consumption (off) | 0.3 W |
| Power consumption (standby) | 0.5 W |
| Power supply type | Internal |
Weight & dimensions
| Depth (with stand) | 242 mm |
| Depth (without stand) | 72 mm |
| Height (with stand) | 457 mm |
| Height (without stand) | 419 mm |
| Weight (without stand) | 6400 g |
| Width (with stand) | 717 mm |
| Width (without stand) | 717 mm |
Packaging data
| Package depth | 200 mm |
| Package height | 538 mm |
| Package width | 990 mm |
Logistics data
| Harmonized System (HS) code | 85285210 |
Energy Efficiency
| Data Sheet (Link) | https://eprel.ec.europa.eu/api/product/2028483/fiches?language=EN |
| Energy efficiency class | G |
| EPREL Registration Number | 2028483 |
| EPREL Version Number | 9 |
