MSI's mainstream MAG series epitomizes stability and durability and is built to withstand the most intense gaming sessions. The entire lineup features robust construction with metallic-like hardness and excellent heat dissipation, ensuring stability for all critical gaming components.
- Windows 11 Home
- Intel Core i5-14400F (20MB Cache)
- NVIDIA GeForce RTX 5060 Ti (16GB GDDR7)
- 16GB (5600MHz) DDR5-SDRAM (2 x 8) & 1000GB SSD
General
| Unit Calculated Weight | 12.6 kg |
| Unit Calculated Volume | 0.09466 cubm |
| Units per Shipping Box | 1 |
| Units per Pallet | 0 |
| Summary | MSI MAG Infinite S3 14NVM5-2873EU. Processor family: Intel® Core™ i5, Processor model: i5-14400F. Internal memory: 16 GB, Internal memory type: DDR5-SDRAM, Memory clock speed: 5600 MHz. Total storage capacity: 1 TB, Storage media: SSD. Discrete graphics card model: NVIDIA GeForce RTX 5060 Ti. Wi-Fi. Operating system installed: Windows 11 Home. Power supply: 500 W. Chassis type: Desktop. Product type: PC. Weight: 7.73 kg. Product colour: Black |
| CnCode | 84714900 |
| Unit Box Height | 0.51 |
| Unit Box Length | 0.58 |
| Unit Box Width | 0.32 |
Design
| Chassis type | Desktop |
| Placement supported | Vertical |
| Product colour | Black |
| Volume | 32 L |
Processor
| Efficient cores | 4 |
| Efficient-core base frequency | 1.8 GHz |
| Efficient-core Max Turbo Frequency | 3.5 GHz |
| Maximum turbo power | 148 W |
| Performance cores | 6 |
| Performance-core base frequency | 2.5 GHz |
| Performance-core Max Turbo Frequency | 4.7 GHz |
| Processor base power | 65 W |
| Processor boost frequency | 4.7 GHz |
| Processor cache | 20 MB |
| Processor cache type | Smart Cache |
| Processor cores | 10 |
| Processor family | Intel® Core™ i5 |
| Processor generation | Intel® Core™ i5 (14th gen) |
| Processor manufacturer | Intel |
| Processor model | i5-14400F |
| Processor threads | 16 |
Memory
| Internal memory | 16 GB |
| Internal memory type | DDR5-SDRAM |
| Maximum internal memory | 64 GB |
| Memory clock speed | 5600 MHz |
| Memory layout (slots x size) | 2 x 8 GB |
| Memory slots | 2x SO-DIMM |
Storage
| Number of SSDs installed | 1 |
| NVMe | Yes |
| Optical drive type | No |
| SSD capacity | 1000 GB |
| SSD form factor | M.2 |
| SSD interface | PCI Express |
| Storage media | SSD |
| Total SSDs capacity | 1000 GB |
| Total storage capacity | 1000 GB |
Graphics
| Discrete GPU manufacturer | NVIDIA |
| Discrete graphics card | Yes |
| Discrete graphics card memory | 16 GB |
| Discrete graphics card model | NVIDIA GeForce RTX 5060 Ti |
| Discrete graphics memory type | GDDR7 |
| On-board graphics card | No |
| On-board graphics card model | Not available |
Network
| Antenna type | 2x2 |
| Bluetooth | Yes |
| Bluetooth version | 5.3 |
| Ethernet LAN | Yes |
| LAN controller | Intel® I219-V |
| Top Wi-Fi standard | Wi-Fi 6 (802.11ax) |
| Wi-Fi | Yes |
| Wi-Fi standards | 802.11a/802.11b/802.11g/Wi-Fi 4 (802.11n)/Wi-Fi 5 (802.11ac)/Wi-Fi 6 (802.11ax) |
| WLAN controller manufacturer | Intel |
| WLAN controller model | Intel Wi-Fi 6E AX210 |
Ports & interfaces
| Combo headphone/mic port | Yes |
| DisplayPort version | 1.4a |
| DisplayPorts quantity | 1 |
| Ethernet LAN (RJ-45) ports | 1 |
| HDMI ports quantity | 1 |
| HDMI version | 1.4 |
| Headphone outputs | 1 |
| Microphone in | Yes |
| USB 2.0 ports quantity | 4 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 3 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity | 1 |
| VGA (D-Sub) ports quantity | 1 |
Performance
| Audio chip | Realtek ALC897 |
| Audio output channels | 7.1 channels |
| Market positioning | Gaming |
| Motherboard chipset | Intel H610 |
| Product type | PC |
Software
| Operating system installed | Windows 11 Home |
Power
| 80 PLUS certification | 80 PLUS Bronze |
| Power supply | 500 W |
Operational conditions
| Operating relative humidity (H-H) | 0 - 85 % |
| Operating temperature (T-T) | 0 - 35 °C |
| Storage relative humidity (H-H) | 0 - 90 % |
| Storage temperature (T-T) | -20 - 60 °C |
Weight & dimensions
| Depth | 446.97 mm |
| Height | 407.17 mm |
| Package depth | 317 mm |
| Package height | 510 mm |
| Package weight | 10440 g |
| Package width | 585 mm |
| Weight | 7730 g |
| Width | 173.8 mm |
Display
| Display included | No |
Other features
| Warranty period | 3 year(s) |
