UNITE AS ONE
The MAG series fights alongside gamers in pursuit of honor.
With added military-inspired elements in these gaming products, they were reborn as the symbol of sturdiness and durability.
MESH CERTIFIED MAKES IT WORK
The front mesh panel allows air to flow into the case easily without obstruction, providing the best system cooling performance. The micro-atx chassis provide small footprint but big perfromance.
HEAT DISSIPATION
You don't need to worry about system cooling with the help of the gaming cases.
HARDWARE COMPATIBILITY
The gaming cases offers extensive support for the installation of your hardware components.
EASY TO INSTALL
The gaming case has many features that make the installation process all the easier.
FANCY APPEARANCE
Build and display the coolest PC with controllable ARGB lighting.
- Supports up to 360 mm AIO liquid cooler and large 40 series GPU
- Supports up to 11 x system fans configuration, providing ventilation and stable performance to the whole system
- Built-in ARGB fans and control board, providing striking lighting and vivid lighting effects
- 1 x USB 3.2 Gen 2x2 Type-C port (20Gbps) & 2 x USB 3.2 Gen 1 Type-A ports (5Gbps)
- Tempered Glass Side Panel displays ARGB lighting effects
- The Magnetic Dust Filter on the top vents being easily remove for cleaning
- LED Switch button provides intuitively control & 9 lighting effects
General
| Unit Calculated Weight | 9 kg |
| Unit Calculated Volume | 0.09086 cubm |
| Units per Shipping Box | 1 |
| Summary | MSI MAG FORGE 321R AIRFLOW. Form factor: Midi Tower, Type: PC, Product colour: Black, Transparent. Power supply location: Bottom, Supported power supply form factors: ATX. Front fans installed: 3x 120 mm, Front fans diameters supported: 120,140 mm, Side fans diameters supported: 120 mm. Supported HDD sizes: 2.5,3.5". Width: 472.5 mm, Depth: 210 mm, Height: 498 mm |
| CnCode | 84733080 |
| Unit Box Height | 0.55 |
| Unit Box Length | 0.59 |
| Unit Box Width | 0.28 |
| Case product features | Transparent panel |
| Model name | MAG FORGE 321R AIRFLOW |
Design
| Anti-dust filter | Yes |
| Form factor | Midi Tower |
| Illumination | Yes |
| Illumination colour | Multi |
| Illumination location | Case fans |
| LED indicators | Yes |
| Material | Mesh/Plastic |
| Maximum CPU cooler height | 160 mm |
| Maximum graphics card length | 390 mm |
| Maximum PSU length | 200 mm |
| Number of 2.5" bays | 2 |
| Number of 3.5" bays | 1 |
| Number of expansion slots | 7 |
| On/off button | Yes |
| Product colour | Black/Transparent |
| Reset button | Yes |
| Side window | Yes |
| Suitable for | Gaming |
| Supported motherboard form factors | ATX/micro ATX/Mini-ITX |
| Tempered glass panel(s) | Yes |
| Type | PC |
Power supply
| Power supply included | No |
| Power supply location | Bottom |
| Supported power supply form factors | ATX |
Ports & interfaces
| Audio input | Yes |
| Audio output | Yes |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 |
Cooling
| Front fans diameters supported | 120/140 mm |
| Front fans installed | 3x 120 mm |
| Number of front fans supported (max) | 3 |
| Number of rear fans supported (max) | 1 |
| Number of side fans supported (max) | 2 |
| Number of top fans supported (max) | 3 |
| Rear fans diameters supported | 120 mm |
| Rear fans installed | 1x 120 mm |
| Side fans diameters supported | 120 mm |
| Top fans diameters supported | 120/140 mm |
Storage
| HDD/SSD combo cage | Yes |
| Supported HDD sizes | 2.5/3.5 " |
Weight & dimensions
| Depth | 210 mm |
| Height | 498 mm |
| Weight | 7050 g |
| Width | 472.5 mm |
Packaging data
| Package weight | 8350 g |
