Highlights
| Product Highlights |
|
Features
| UPS Topology | Line-Interactive |
| Output Power Capacity | 1 kVA |
| Output Power | 1000 W |
| Waveform | Pure sine |
| Input Operation Voltage (min) | 160 V |
| Input Operation Voltage (max) | 294 V |
| Input Frequency | 47/70 Hz |
| Noise Level | 40 dB |
Ports & Interfaces
| AC Outlet Types | C13 coupler |
| Power Plug | C14 coupler |
| AC Outlets Quantity | 8 AC outlet(s) |
| USB Port | Yes |
| Serial Interface | Yes |
| Serial Interface Type | RS-232 |
| Serial Ports Quantity | 1 |
Battery
| Typical Backup Time At Half Load | 17 min |
| Hot-swap Battery | Yes |
Design
| Form Factor | Rackmount/Tower |
| Product Colour | Black |
| Display Type | LCD |
Operational Conditions
| Operating Temperature (T-T) | 0 - 40 °C |
Weight & Dimensions
| Width | 438 mm |
| Depth | 448 mm |
| Height | 85.5 mm |
| Weight | 19.6 kg |
Warranty and Other
| Warranty Terms | 12 months |
| Product Condition | Original |
| Manufacturer Datasheet | https://www.tdbaltic.ee/leaflets/EATON/5PX1000IRTNG2.pdf |
