Highlights
| Product Highlights |
|
Features
| UPS Topology | Line-Interactive |
| Output Power Capacity | 2.2 kVA |
| Output Power | 1980 W |
| Waveform | Sine |
| Input Operation Voltage (min) | 151 V |
| Input Operation Voltage (max) | 302 V |
| Input Frequency | 50/60 Hz |
| Output Operation Voltage (min) | 220 V |
| Output Operation Voltage (max) | 240 V |
| Noise Level | 55 dB |
Ports & Interfaces
| AC Outlet Types | C13 coupler, C19 coupler |
| AC Outlets Quantity | 9 AC outlet(s) |
| USB Port | Yes |
| USB Port Type | USB Type-A |
| Serial Interface | Yes |
| Serial Interface Type | RJ-45 |
Battery
| Battery Technology | Sealed Lead Acid (VRLA) |
Design
| Form Factor | Rackmount |
| Product Colour | Black, Metallic |
| Display Type | LCD |
Operational Conditions
| Operating Temperature (T-T) | 0 - 40 °C |
| Operating Relative Humidity (H-H) | 0 - 95% |
| Operating Altitude | 0 - 3000 m |
Packaging Content
| Rack Mount Kit | Yes |
| Cables Included | RS-232, USB cable |
Weight & Dimensions
| Width | 432 mm |
| Depth | 683 mm |
| Height | 86 mm |
| Weight | 42.3 kg |
Warranty and Other
| Warranty Terms | 12 months |
| Product Condition | Original |
| Manufacturer Datasheet | https://www.tdbaltic.ee/leaflets/APC/SMT2200RMI2UC.pdf |
