Highlights
| Product Highlights |
|
Features
| UPS Topology | Line-Interactive |
| Output Power | 680 W |
| Waveform | Sine |
| Input Operation Voltage (min) | 160 V |
| Input Operation Voltage (max) | 294 V |
| Input Frequency | 47/70 Hz |
| Output Operation Voltage (max) | 230 V |
| Output Frequency | 50/60 Hz |
| Number of Input Phases | 1 |
| Number of Output Phases | 1 |
| Efficiency | 98% |
| Noise Level | 35 dB |
Ports & Interfaces
| AC Outlet Types | C13 coupler |
| Power Plug | C14 coupler |
| AC Outlets Quantity | 6 AC outlet(s) |
| USB Port | Yes |
| Serial Interface | Yes |
| Serial Interface Type | RS-232 |
| Serial Ports Quantity | 1 |
Battery
| Battery Technology | Lead-Acid |
| Battery Capacity | 7 Ah |
| Battery Voltage | 12 V |
Design
| Form Factor | Tower |
| Product Colour | Black, Silver |
| Display Type | LCD |
Operational Conditions
| Operating Temperature (T-T) | 0 - 40 °C |
| Operating Relative Humidity (H-H) | 0 - 90% |
| Operating Altitude | 0 - 3000 m |
Packaging Content
| Rack Mount Kit | No |
| Cables Included | USB cable |
| Quick Installation Guide | Yes |
Weight & Dimensions
| Width | 150 mm |
| Depth | 345 mm |
| Height | 233 mm |
| Weight | 10.2 kg |
Warranty and Other
| Warranty Terms | 24 months |
| Product Condition | Original |
| Manufacturer Datasheet | https://www.tdbaltic.ee/leaflets/EATON/5P850IG2SPEC.pdf |
