Highlights
| Product Highlights |
|
Features
| UPS Topology | Standby (Offline) |
| Output Power Capacity | 0.85 kVA |
| Output Power | 520 W |
| Waveform | Sine |
| Input Operation Voltage (min) | 220 V |
| Input Operation Voltage (max) | 230 V |
| Input Frequency | 47/63 Hz |
| Output Operation Voltage (min) | 220 V |
| Output Operation Voltage (max) | 230 V |
| Output Frequency | 47/63 Hz |
| Automatic Voltage Regulation (AVR) | No |
| Noise Level | 45 dB |
Ports & Interfaces
| AC Outlet Types | Type F |
| Power Plug | Type F |
| AC Outlets Quantity | 8 AC outlet(s) |
| USB Port | Yes |
Battery
| Battery Technology | Sealed Lead Acid (VRLA) |
| Battery Capacity | 93 Ah |
| Typical Backup Time At Half Load | 9 min |
| Hot-swap Battery | Yes |
Design
| Form Factor | Compact |
| Product Colour | Black |
Operational Conditions
| Operating Temperature (T-T) | 0 - 40 °C |
| Operating Relative Humidity (H-H) | 0 - 90% |
| Operating Altitude | 0 - 900 m |
Weight & Dimensions
| Width | 130 mm |
| Depth | 365 mm |
| Height | 120 mm |
| Weight | 4.5 kg |
Warranty and Other
| Warranty Terms | 24 months |
| Product Condition | Original |
