Highlights
| Product Highlights |
|
Features
| UPS Topology | Line-Interactive |
| Output Power Capacity | 0.95 kVA |
| Output Power | 520 W |
| Waveform | Sine |
| Input Operation Voltage (min) | 140 V |
| Input Operation Voltage (max) | 300 V |
| Input Frequency | 50/60 Hz |
| Output Operation Voltage (min) | 230 V |
| Output Operation Voltage (max) | 230 V |
| Output Frequency | 50/60 Hz |
| Automatic Voltage Regulation (AVR) | Yes |
| Noise Level | 40 dB |
Ports & Interfaces
| AC Outlet Types | Type F |
| Power Plug | Type F |
| AC Outlets Quantity | 4 AC outlet(s) |
| USB Port | Yes |
| USB Port Type | USB Type-B |
Battery
| Battery Technology | Sealed Lead Acid (VRLA) |
| Typical Backup Time At Half Load | 6.5 min |
Design
| Form Factor | Compact |
| Product Colour | Black |
Operational Conditions
| Operating Temperature (T-T) | 0 - 40 °C |
| Operating Relative Humidity (H-H) | 0 - 95% |
| Operating Altitude | 0 - 3000 m |
Packaging Content
| Cables Included | Input power cable |
Weight & Dimensions
| Width | 120 mm |
| Depth | 355 mm |
| Height | 160 mm |
| Weight | 6.1 kg |
Warranty and Other
| Warranty Terms | 24 months |
| Product Condition | Original |
| Manufacturer Datasheet | https://www.tdbaltic.ee/leaflets/APC/BX950MI-GR.pdf |
