PROJECTOR X1526 4000 LUMENS/MR.JX911.001 ACER
General
| Unit Calculated Weight | 3.3 kg |
| Unit Calculated Volume | 0.0177 cubm |
| Summary | Acer X1526. Projector brightness: 4000 ANSI lumens, Projection technology: DLP, Projector native resolution: 1080p (1920x1080). Light source type: Lamp, Service life of light source: 4000 h, Service life of light source (economic mode): 10000 h. Focus: Manual, Focal length range: 22 - 24.1 mm, Aperture range (F-F): 2.56 - 2.68. Analog signal format system: NTSC, PAL, SECAM, Supported graphics resolutions: 1920 x 1080 (HD 1080), 1920 x 1200 (WUXGA). Serial interface type: RS-232 |
| Unit Box Height | 0.295 |
| Unit Box Length | 0.4 |
| Unit Box Width | 0.15 |
| Model | X1526 |
Projector
| Contrast ratio (typical) | 10000:1 |
| Horizontal scan range | 15 - 100 kHz |
| Keystone correction, vertical | -40 - 40 ° |
| Native aspect ratio | 16:9 |
| Number of colours | 1.07 billion colours |
| Projection distance | 1 - 10 m |
| Projection technology | DLP |
| Projector brightness | 4000 ANSI lumens |
| Projector brightness (economic mode) | 3200 ANSI lumens |
| Projector native resolution | 1080p (1920x1080) |
| Supported aspect ratios | 16:9/4:3 |
| Uniformity | 85 % |
| Vertical scan range | 24 - 120 Hz |
Light source
| Lamp power | 245 W |
| Lamp type | P-VIP |
| Lamps quantity | 1 lamp(s) |
| Light source type | Lamp |
| Service life of light source | 4000 h |
| Service life of light source (economic mode) | 10000 h |
Lens system
| Aperture range (F-F) | 2.56 - 2.68 |
| Focal length range | 22 - 24.1 mm |
| Focus | Manual |
| Offset | 116 % |
| Zoom capability | Yes |
| Zoom ratio | 1.1:1 |
| Zoom type | Manual |
Video
| 3D | No |
| Analog signal format system | NTSC/PAL/SECAM |
| Full HD | Yes |
| Supported graphics resolutions | 1920 x 1080 (HD 1080)/1920 x 1200 (WUXGA) |
Ports & interfaces
| Audio (L/R) in | 1 |
| Audio (L/R) out | 1 |
| HDMI ports quantity | 2 |
| HDMI version | 1.4 |
| Mobile High-Definition Link (MHL) | No |
| PC Audio in | Yes |
| PC Audio out | Yes |
| Serial interface type | RS-232 |
| USB 2.0 Type-A ports quantity | 1 |
Network
| Ethernet LAN | No |
| Smart TV | No |
Storage
| Card reader integrated | No |
Features
| Interactive | No |
| Noise level | 29 dB |
| Projection modes | Ceiling,Front,Rear |
Multimedia
| Built-in speaker(s) | Yes |
| Number of built-in speakers | 1 |
| RMS rated power | 3 W |
Design
| Market positioning | Business |
| Placement | Ceiling |
| Product colour | White |
| Product type | Standard throw projector |
Display
| Built-in display | No |
Power
| AC input frequency | 50 Hz |
| AC input voltage | 120 - 230 V |
| Power consumption (standby) | 0.5 W |
| Power consumption (typical) | 260 W |
| Power source | AC |
Operational conditions
| Operating temperature (T-T) | 0 - 40 °C |
Weight & dimensions
| Depth | 220 mm |
| Height | 105.1 mm |
| Weight | 2400 g |
| Width | 299.5 mm |
Packaging content
| Batteries included | Yes |
| Cables included | AC |
| Manual | Yes |
| Remote control included | Yes |
Logistics data
| Quantity per pack | 1 pc(s) |
