The Neomounts desk mount, model NM-D335D4BLACK is a tilt-, swivel and rotatable desk mount for 4 flat screens up to 27". This mount is a great choice for space saving placement on desks using a desk clamp, desk stand or desk grommet.
Neomounts versatile tilt (90°), rotate (360°) and swivel (30°) technology allows the mount to change to any viewing angle to fully benefit from the capabilities of the flat screen. The mount is manually height adjustable from 0 to 80 centimetres.An innovative cable management conceals and routes cables from mount to flat screen. Hide your cables to keep the workplace nice and tidy.
Neomounts NM-D335D4BLACK has one pivot point and is suitable for 4 screens up to 27" (69 cm). The weight capacity of this product is 8 kg each screen. The desk mount is suitable for screens that meet VESA hole pattern 75x75 or 100x100mm. Different hole patterns can be covered using Neomounts VESA adapter plates.
By using an ergonomic mount neck- and back complaints can be avoided. Ideal for use in offices and on counters or in a reception area.
All installation material is included with the product.
General
| Unit Calculated Weight | 9.9 kg |
| Unit Calculated Volume | 0.02094 cubm |
| Units per Shipping Box | 1 |
| Summary | Neomounts NM-D335D4BLACK Monitor stand 10-27". Mounting: Clamp/Freestanding/Grommet, Maximum weight capacity: 8 kg, Minimum screen size: 25.4 cm (10"), Maximum screen size: 68.6 cm (27"), Minimum VESA mount: 75 x 75 mm, Maximum VESA mount: 100 x 100 mm. Height adjustment, Swivel angle range: -15 - 15°, Tilt angle range: -45 - 45°. Product colour: Black |
| CnCode | 83021000 |
| Unit Box Height | 0.33 |
| Unit Box Length | 0.47 |
| Unit Box Width | 0.135 |
Mounting
| Desk thickness (max) | 90 mm |
| Distance to the wall (max) | 80 mm |
| Maximum screen size | 27 " |
| Maximum VESA mount | 100 x 100 mm |
| Maximum weight capacity | 8 kg |
| Maximum weight capacity (per display) | 8 kg |
| Minimum screen size | 10 " |
| Minimum VESA mount | 75 x 75 mm |
| Mounting | Clamp/Freestanding/Grommet |
| Mounting type | Desk |
| Number of displays supported | 4 |
| Panel mounting interface | 100 x 100/75 x 75 mm |
Ergonomics
| Angle of rotation | 360 ° |
| Depth adjustment range | 0 - 80 mm |
| Height adjustment | Yes |
| Height adjustment range | 0 - 810 mm |
| Height adjustment type | Manual |
| Pivot angle | -180 - 180 ° |
| Rotating | Yes |
| Swivel angle | 30 ° |
| Swivel angle range | -15 - 15 ° |
| Swivelling | Yes |
| Tilt adjustment | Yes |
| Tilt angle range | -45 - 45 ° |
Design
| Housing material | Steel |
| Product colour | Black |
Weight & dimensions
| Depth | 80 mm |
| Height | 810 mm |
| Weight | 8380 g |
Packaging data
| Package depth | 132 mm |
| Package height | 460 mm |
| Package weight | 9900 g |
| Package width | 326 mm |
Logistics data
| Country of origin | China |
| Harmonized System (HS) code | 7326909890 |
| Master (outer) case gross weight | 21600 g |
| Master (outer) case height | 340 mm |
| Master (outer) case length | 280 mm |
| Master (outer) case net weight | 19800 g |
| Master (outer) case width | 475 mm |
| Products per master (outer) case | 2 pc(s) |
| Products per pallet (EU) | 36 pc(s) |
