Outstanding Single-Tower Cooling
NX400 features a meticulously engineered heat sink paired with a
high-performance static-pressure fan. Designed for maximum cooling efficiency in a compact form, delivering exceptional heat dissipation with a streamlined structure.
General
| Unit Calculated Weight | 0.946 kg |
| Unit Calculated Volume | 0.004264 cubm |
| Units per Shipping Box | 12 |
| Summary | Montech NX400 ARGB. Type: Air cooler, Fan diameter: 12 cm, Rotational speed (min): 800 RPM, Rotational speed (max): 1950 RPM, Maximum air pressure: 2.82 mmH2O, Bearing type: Fluid Dynamic Bearing (FDB). Voltage: 12 V. Width: 156 mm, Depth: 74 mm, Height: 120 mm. Product colour: Black |
| Unit Box Height | 0.41 |
| Unit Box Length | 0.48 |
| Unit Box Width | 0.0217 |
| Model name | NX400 ARGB |
Performance
| Bearing type | Fluid Dynamic Bearing (FDB) |
| Fan 2 maximum air pressure | 3.35 mmH2O |
| Fan 2 maximum airflow | 85.09 cfm |
| Fan 2 noise level (high speed) | 34.17 dB |
| Fan 2 rotational speed (max) | 1950 RPM |
| Fan 2 rotational speed (min) | 800 RPM |
| Fan diameter | 120 mm |
| Fan diameter 2 | 120 mm |
| Fan speed (max) | 2000 RPM |
| Fan speed (min) | 800 RPM |
| Maximum air pressure | 2.82 mmH2O |
| Maximum airflow | 69 cfm |
| Noise level (high speed) | 26 dB |
| Quantity per pack | 2 pc(s) |
| Rotational speed (max) | 1950 RPM |
| Rotational speed (min) | 800 RPM |
| Suitable location | Processor |
| Type | Air cooler |
Design
| Fan connector | 4-pin |
| Fins material | Aluminium |
| Illumination colour | Amber/Blue/Green/Red |
| Illumination LED | Yes |
| LED connector type | 3-pin |
| Material | Aluminium/Copper/Plastic |
| Number of fan blades | 9 |
| Number of fans | 1 fan(s) |
| Number of fins | 104 |
| Number of heat pipes | 4 |
| Product colour | Black |
| Radiator material | Aluminum |
Power
| Thermal Design Power (TDP) | 270 W |
| Voltage | 12 V |
Weight & dimensions
| Depth | 74 mm |
| Fan dimensions (W x D x H) | 120 x 120 x 25 mm |
| Height | 120 mm |
| Tube diameter | 6 mm |
| Weight | 874 g |
| Width | 156 mm |
Technical details
| Warranty period | 3 year(s) |
Packaging content
| Mounting kit | Yes |
