Patriot is proud to present its next generation 2.5” SATA III SSD: The P220. Designed with the latest SATA 3 controller, the P220 is a premier storage solution designed for top system performance. With read and write speeds of up to 550 and 500 MB/s, the P220 gives you the performance you need to get the job done.
As a 7mm high 2.5” form factor SSD, the P220 is a compact storage drive that provides stronger overall performance and productivity. The P220 is perfect for fast upgrades, storing large files and providing efficiency in your workspace for a great price.
Backed by Patriot’s 3-year warranty and customer service, Patriot’s P220 SSD stands as one of the most reliable and strong price-to-performance SSDs on the market today.
General
| Unit Calculated Weight | 0.063 kg |
| Unit Calculated Volume | 0.0002504 cubm |
| Units per Shipping Box | 30 |
| Units per Pallet | 0 |
| Summary | Patriot Memory P220 256GB. SSD capacity: 256 GB, SSD form factor: 2.5", Component for: PC/Laptop |
| CnCode | 84717098 |
| Unit Box Height | 0.01 |
| Unit Box Length | 0.18 |
| Unit Box Width | 0.135 |
| SSD series | P220 |
Features
| Component for | PC/Laptop |
| Interface | Serial ATA III |
| Random read (4KB) | 40000 IOPS |
| Random write (4KB) | 50000 IOPS |
| S.M.A.R.T. support | Yes |
| Sequential read speed (CDM) | 550 MB/s |
| Sequential write speed (CDM) | 490 MB/s |
| SSD capacity | 256 GB |
| SSD form factor | 2.5" |
| TRIM support | Yes |
| Windows operating systems supported | Windows 10/Windows 7/Windows 8/Windows 8.1 |
Weight & dimensions
| Depth | 100 mm |
| Height | 7 mm |
| Weight | 46 g |
| Width | 69.9 mm |
Packaging data
| Package depth | 80 mm |
| Package height | 178 mm |
| Package type | Hanging box |
| Package weight | 50 g |
| Package width | 133 mm |
Operational conditions
| Operating temperature (T-T) | 0 - 70 °C |
Other features
| Compliance certificates | CE/Federal Communications Commission (FCC)/RoHS |
Logistics data
| Master (outer) case height | 195 mm |
| Master (outer) case length | 394 mm |
| Master (outer) case net weight | 6000 g |
| Master (outer) case width | 324 mm |
| Products per master (outer) case | 120 pc(s) |
