The Active Defense Series Small PT Camera delivers advanced performance and functionality. Upon detecting an intrusion, it promptly activates sound and light alarms, while simultaneously transmitting critical information to your mobile device for instant alerts. The camera also features two-way talk, enabling real-time communication with individuals on the site. Additionally, its Smart Dual Illuminator enhances visibility, allowing the camera to capture clear, full-color videos and images whether day or night, thereby providing reliable evidence of events while minimizing light pollution. Thanks to its 4G network capability, the camera also delivers continuous surveillance, even in areas with limited Wi-Fi access, making it an ideal choice for remote outdoor locations such as farms, ranches and orchards.
- Clear images with sharp details
- Focuses on what matters and reduces false alarms
- Provides instant alarms to deter intruders
- Withstands harsh environments
- Expands your connectivity with 4G
- Communication anytime, anywhere
- Advanced H.265 compression technology
- 360° monitoring without blind spots
- Captures color details for post-event review
General
| Unit Calculated Weight | 0.76 kg |
| Unit Calculated Volume | 0.004499 cubm |
| Units per Shipping Box | 1 |
| Units per Pallet | 0 |
| Summary | Dahua Technology 3MP Fixed-focal 4G Pan & Tilt Network Camera. Type: IP security camera, Placement supported: Outdoor, Connectivity technology: Wireless. Mounting type: Ceiling/wall, Product colour: Black, White, Form factor: Turret. Angle of rotation: 180°, Lens viewing angle, horizontal: 73.85°, Lens viewing angle, vertical: 43.43°. Sensor type: CMOS, Optical sensor size: 25.4 / 2.8 mm (1 / 2.8"). Fixed focal length: 4 mm |
| Unit Box Height | 0.22 |
| Unit Box Length | 0.143 |
| Unit Box Width | 0.143 |
| Model name | P3AE-PV-4G |
Performance
| Auto-tracking | Yes |
| Built-in light | Yes |
| Connectivity technology | Wireless |
| Day/night mode | Yes |
| Placement supported | Outdoor |
| Plug and Play | Yes |
| PTZ control | Yes |
| Type | IP security camera |
| Wide Dynamic Range (WDR) | Yes |
Design
| Form factor | Turret |
| Housing material | Plastic |
| International Protection (IP) code | IP66 |
| LED indicators | Yes |
| Mounting type | Ceiling/wall |
| Product colour | Black/White |
| Protection features | Dustproof/Rain proof/Waterproof/Wind resistant |
| Weatherproof | Yes |
Camera
| Angle of rotation | 180 ° |
| Camera pan control | Yes |
| Camera shutter speed | 1/25 - 1/100000 s |
| Camera shutter type | Electronic |
| Camera tilt control | Yes |
| Lens viewing angle, diagonal | 86.56 ° |
| Lens viewing angle, horizontal | 73.85 ° |
| Lens viewing angle, vertical | 43.43 ° |
| Pan range | 0 - 345 ° |
| Tilt angle range | 0 - 90 ° |
Panoramic camera
| Digital Wide Dynamic Range (DWDR) (panoramic camera) | Yes |
Image sensor
| Optical sensor size | 1/2.8 " |
| Sensor type | CMOS |
Lens system
| Fixed focal length | 4 mm |
| Fixed focus | Yes |
| Maximum aperture number | 1.6 |
Night vision
| LED type | IR/White |
| Night vision | Yes |
| Night vision distance | 30 m |
| Number of illumination LEDs | 4 |
Video
| Bit rate | H264: 64 - 8192 kbps H265: 25 - 6400 kbps |
| Maximum resolution | 2304 x 1296 pixels |
| Total megapixels | 3 MP |
| Video compression formats | H.264+/H.264B/H.264H/H.264M/H.265/H.265+/M-JPEG |
| Video streaming | Yes |
Audio
| Audio system | 2-way |
| Built-in microphone | Yes |
| Built-in speaker(s) | Yes |
| Voice codecs | G.711a/G.711Mu/G.726/PCM |
Network
| 4G standard | LTE-FDD |
| Bluetooth | No |
| Ethernet LAN | No |
| Live view | Yes |
| Mobile network connection | Yes |
| Mobile network generation | 4G |
| SIM card slot | Yes |
| Wi-Fi | No |
Storage
| Built-in HDD | No |
| Card reader integrated | Yes |
| Compatible memory cards | MicroSD (TransFlash) |
| Maximum memory card size | 256 GB |
Security
| Alert notification type | Push notification |
| Intelligent Video Surveillance (IVS) system features | Human detection/Intrusion/Tripwire/Vehicle detection |
| Privacy protection | Yes |
| Video motion detection | Yes |
Management features
| Management software | DMSS |
| Remotely operated | Yes |
| Reset button | Yes |
Power
| DC output current | 1 A |
| DC output voltage | 12 |
| Power consumption (max) | 9 W |
| Power consumption (typical) | 3 W |
| Power source type | DC |
| Surge protection voltage | 2 kV |
Operational conditions
| Operating relative humidity (H-H) | 0 - 95 % |
| Operating temperature (T-T) | -30 - 55 °C |
System requirements
| Mobile operating systems supported | Android/iOS |
Weight & dimensions
| Diameter | 111 mm |
| Height | 140.5 mm |
| Weight | 500 g |
Sustainability
| Compliance certificates | CE |
Packaging content
| AC adapter included | Yes |
| Mounting brackets included | Yes |
| Number of cameras | 1 |
| Quick start guide | Yes |
| Screws included | Yes |
Technical details
| Iris | Yes |
