The Active Defense series of small PT cameras raises the bar on performance. After detecting an intrusion, it triggers sound and light alarms, and then instantly relays vital information on the intrusion to the mobile client, keeping you informed no matter where you are. It supports two-way talk, allowing you to communicate with people in front of the camera in real time. Additionally, it includes smart dual light that not only reduce light pollution, but also intelligently turn on when they are triggered by an event to assist the camera with capturing clear, full-color videos.
General
| Unit Calculated Weight | 0.723 kg |
| Unit Calculated Volume | 0.00425 cubm |
| Units per Shipping Box | 30 |
| Units per Pallet | 0 |
| Summary | Dahua Technology 3MP Outdoor Fixed-focal Wi-Fi Pan & Tilt Network Camera. Type: IP security camera, Placement supported: Indoor & outdoor, Connectivity technology: Wired & Wireless. Mounting type: Ceiling/Wall/Desk, Product colour: White, Form factor: Turret. Angle of rotation: 180°, Lens viewing angle, horizontal: 87°, Lens viewing angle, vertical: 49°. Sensor type: CMOS, Optical sensor size: 25.4 / 3.2 mm (1 / 3.2"). Fixed focal length: 2.8 mm |
| Unit Box Height | 0.209 |
| Unit Box Length | 0.134 |
| Unit Box Width | 0.134 |
| Model name | 3MP Outdoor Fixed-focal Wi-Fi Pan & Tilt Network Camera |
Performance
| Auto-tracking | Yes |
| Connectivity technology | Wired & Wireless |
| Day/night mode | Yes |
| Placement supported | Indoor & outdoor |
| Type | IP security camera |
| Wide Dynamic Range (WDR) | Yes |
Design
| Form factor | Turret |
| Housing material | Plastic |
| International Protection (IP) code | IP66 |
| Mounting type | Ceiling/Wall/Desk |
| Product colour | White |
| Protection features | Rain proof/Weather resistant/Wind resistant |
Camera
| Angle of rotation | 180 ° |
| Camera pan control | Yes |
| Camera tilt control | Yes |
| Lens viewing angle, diagonal | 101 ° |
| Lens viewing angle, horizontal | 87 ° |
| Lens viewing angle, vertical | 49 ° |
| Pan range | 0 - 350 ° |
| Tilt angle range | 0 - 90 ° |
Panoramic camera
| Digital Wide Dynamic Range (DWDR) (panoramic camera) | Yes |
Image sensor
| Optical sensor size | 1/3.2 " |
| Sensor type | CMOS |
Lens system
| Fixed focal length | 2.8 mm |
| Fixed focus | Yes |
| Maximum aperture number | 2 |
Night vision
| LED type | IR/White |
| Night vision | Yes |
| Night vision distance | 30 m |
| Number of illumination LEDs | 4 |
Video
| Maximum resolution | 2304 x 1296 pixels |
| Supported graphics resolutions | 2304 x 1296 |
| Supported video modes | 1296p |
| Total megapixels | 3 MP |
| Video compression formats | H.265 |
| Video streaming | Yes |
Audio
| Audio system | 2-way |
| Bit rate range | 80 - 4096 Kbit/s |
| Built-in microphone | Yes |
| Built-in speaker(s) | Yes |
| Voice codecs | G.711a/G.711Mu/G.726/PCM |
Network
| Bluetooth | Yes |
| Ethernet interface type | Fast Ethernet |
| Ethernet LAN | Yes |
| Frequency band | 2.4 GHz |
| Wi-Fi | Yes |
| Wi-Fi standards | 802.11b/802.11g/Wi-Fi 4 (802.11n)/Wi-Fi 6 (802.11ax) |
Storage
| Built-in HDD | No |
| Card reader integrated | Yes |
| Compatible memory cards | MicroSD (TransFlash) |
| Maximum memory card size | 256 GB |
Ports & interfaces
| Ethernet LAN (RJ-45) ports | 1 |
| Interface | RJ-45/WLAN |
Security
| Intelligent Video Surveillance (IVS) system features | Human detection/Vehicle detection |
| Video motion detection | Yes |
Management features
| Reset button | Yes |
Power
| DC output voltage | 12 |
| Power consumption (max) | 11.1 W |
| Power consumption (typical) | 1.7 W |
| Power source type | DC |
Operational conditions
| Operating relative humidity (H-H) | 0 - 95 % |
| Operating temperature (T-T) | -30 - 50 °C |
System requirements
| Mobile operating systems supported | Android/iOS |
Weight & dimensions
| Height | 135 mm |
| Length | 136 mm |
| Weight | 336 g |
| Width | 105 mm |
Sustainability
| Compliance certificates | CE/Electromagnetic Compatibility (EMC)/Low Voltage Directive (LVD) |
Packaging content
| AC adapter included | Yes |
| Mounting kit | Yes |
| Number of cameras | 1 |
| Quick start guide | Yes |
Other features
| Data transfer rate | 100 Mbit/s |
