The Active Defense series of small PT cameras raises the bar on performance. After detecting an intrusion, it triggers sound and light alarms, and then instantly relays vital information on the intrusion to the mobile client, keeping you informed no matter where you are. It supports two-way talk, allowing you to communicate with people in front of the camera in real time. Additionally, it includes smart dual light that not only reduce light pollution, but also intelligently turn on when they are triggered by an event to assist the camera with capturing clear, full-color videos.
General
| Unit Calculated Weight | 0.727 kg |
| Unit Calculated Volume | 0.004515 cubm |
| Units per Shipping Box | 30 |
| Units per Pallet | 0 |
| Summary | Dahua Technology 5MP Outdoor Fixed-focal Wi-Fi Pan & Tilt Network Camera. Type: IP security camera, Placement supported: Indoor & outdoor, Connectivity technology: Wired & Wireless. Mounting type: Ceiling/Wall/Desk, Product colour: White, Form factor: Dome. Lens viewing angle, horizontal: 95°, Lens viewing angle, vertical: 53°, Lens viewing angle, diagonal: 110°. Sensor type: CMOS, Optical sensor size: 25.4 / 3.2 mm (1 / 3.2"). Fixed focal length: 2.8 mm |
| Unit Box Height | 0.209 |
| Unit Box Length | 0.134 |
| Unit Box Width | 0.134 |
| Model name | 5MP Outdoor Fixed-focal Wi-Fi Pan & Tilt Network Camera |
Performance
| Auto-tracking | Yes |
| Built-in light | Yes |
| Certification | CE-LVD: EN62368-1; CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU; CE-RED: Radio Equipment Directive 2014/53/EU |
| Connectivity technology | Wired & Wireless |
| Day/night mode | Yes |
| Placement supported | Indoor & outdoor |
| Type | IP security camera |
| Wide Dynamic Range (WDR) | Yes |
Design
| Form factor | Dome |
| Housing material | Plastic |
| International Protection (IP) code | IP66 |
| Mounting type | Ceiling/Wall/Desk |
| Product colour | White |
| Protection features | Dustproof/Rain proof/Wind resistant |
| Weatherproof | Yes |
Camera
| Camera pan control | Yes |
| Camera tilt control | Yes |
| Lens viewing angle, diagonal | 110 ° |
| Lens viewing angle, horizontal | 95 ° |
| Lens viewing angle, vertical | 53 ° |
| Pan range | 0 - 350 ° |
| Tilt angle range | 0 - 90 ° |
Image sensor
| Optical sensor size | 1/3.2 " |
| Sensor type | CMOS |
Lens system
| Fixed focal length | 2.8 mm |
| Fixed focus | Yes |
| Maximum aperture number | 2 |
| Number of lenses | 1 |
Night vision
| LED type | IR/White |
| Night vision | Yes |
| Night vision distance | 30 m |
| Number of illumination LEDs | 4 |
Video
| Bit rate | 32 kbps-6144 kbps |
| Digital Wide Dynamic Range (DWDR) | Yes |
| Frame rate | 15 fps |
| Maximum resolution | 2880 x 1620 pixels |
| Supported graphics resolutions | 2880 x 1620 |
| Supported video modes | 1620p |
| Total megapixels | 5 MP |
| Video compression formats | H.265 |
| Video streaming | Yes |
Audio
| Audio codecs | G.711a; G.711Mu; PCM; G.726 |
| Audio system | 2-way |
| Built-in microphone | Yes |
| Built-in speaker(s) | Yes |
Network
| Bluetooth | Yes |
| Cabling technology | 10/100Base-T(X) |
| Ethernet interface type | Fast Ethernet |
| Ethernet LAN | Yes |
| Wi-Fi | Yes |
| Wi-Fi standards | 802.11a/802.11b/802.11g/Wi-Fi 4 (802.11n)/Wi-Fi 6 (802.11ax) |
Storage
| Built-in HDD | No |
| Card reader integrated | Yes |
| Compatible memory cards | MicroSD (TransFlash) |
| Maximum memory card size | 256 GB |
Ports & interfaces
| Ethernet LAN (RJ-45) ports | 1 |
Security
| Built-in siren | Yes |
| Intelligent Video Surveillance (IVS) system features | Human detection/Vehicle detection |
| Video motion detection | Yes |
Management features
| Management software | Smart PSS Lite; DMSS |
| Reset button | Yes |
Power
| DC output voltage | 12 |
| Power consumption (max) | 11.3 W |
| Power consumption (typical) | 2.2 W |
| Power source type | DC |
Operational conditions
| Operating relative humidity (H-H) | 0 - 95 % |
| Operating temperature (T-T) | -30 - 50 °C |
System requirements
| Mobile operating systems supported | Android/iOS |
Weight & dimensions
| Depth | 136 mm |
| Height | 135 mm |
| Weight | 336 g |
| Width | 105 mm |
Packaging content
| AC adapter included | Yes |
| Mounting kit | Yes |
| Number of cameras | 1 |
| Quick start guide | Yes |
Other features
| Data transfer rate | 100 Mbit/s |
