Keychron Q1 HE
Meet the Q1 HE, the world's first 75% layout wireless QMK custom keyboard equipped with Hall Effect Gateron double-rail magnetic switches. These switches provide a distinct advantage due to their unique mechanism, offering faster feedback, dynamic rapid triggering, and adjustable actuation points, resulting in epic enhancements for the gaming experience tailored to your individual preferences.
- The keyboard PCB, the case, and the aluminum plate
- Keycaps (included Mac & Windows keycaps)
- Adjustable-actuation-point Gateron double-rail magnetic switches
General
| Unit Calculated Weight | 2.56 kg |
| Unit Calculated Volume | 0.006817 cubm |
| Units per Shipping Box | 5 |
| Units per Pallet | 0 |
| Summary | Keychron Q1 HE. Keyboard form factor: 75%. Keyboard style: Straight. Connectivity technology: Wired & Wireless, Device interface: USB + RF Wireless + Bluetooth, Keyboard key switch: Magnetic-mechanical key switch. Backlight type: RGB LED. Cable length: 1.8 m. Recommended usage: Universal. Product colour: Black, Grey |
| CnCode | 84716060 |
| Unit Box Height | 0.075 |
| Unit Box Length | 0.365 |
| Unit Box Width | 0.205 |
Keyboard
| Actuation force | 60 g |
| Bluetooth version | 5.1 |
| Built-in memory | Yes |
| Built-in memory capacity | 256 KB |
| Connectivity technology | Wired & Wireless |
| Device interface | USB + RF Wireless + Bluetooth |
| Frequency band | 2.4 GHz |
| Keyboard form factor | 75% |
| Keyboard key profile | High-profile |
| Keyboard key switch | Magnetic-mechanical key switch |
| Keyboard keys operating life | 150 million characters |
| Keycaps | Double shot |
| Keycaps material | Polybutylene terephthalate (PBT) |
| Numeric keypad | No |
| Pointing device | No |
| Polling rate | 1000/90 Hz |
| Programmable hot keys | Yes |
| Recommended usage | Universal |
| Rollover | N-key rollover |
Design
| Adjustable backlight | Yes |
| Adjustable keyboard height | Yes |
| Backlight | Yes |
| Backlight colour | Red/Green/Blue |
| Backlight type | RGB LED |
| Keyboard style | Straight |
| Material | Aluminium |
| Product colour | Black/Grey |
Features
| Cable length | 1.8 m |
| Detachable cable | Yes |
| Hot-swap | Yes |
| USB connector type | USB Type-C |
Power
| Battery capacity | 4000 mAh |
| Battery life (max) | 100 h |
| Battery technology | Lithium Polymer (LiPo) |
| Keyboard battery type | Built-in battery |
| Power source type | Battery,USB |
| Rechargeable | Yes |
| USB Type-C charging port | Yes |
Mouse
| Mouse included | No |
Operational conditions
| Operating temperature (T-T) | -10 - 50 °C |
Weight & dimensions
| Keyboard dimensions (WxDxH) | 372.5 x 145 x 35.8 mm |
| Keyboard weight | 1735 g |
Packaging content
| AC adapter included | No |
| Number of products included | 1 pc(s) |
| Receiver included | Yes |
