03-12 (143)
Highlights
| Product Highlights |
|
Features
| 2.4 GHz | Yes |
| 5 GHz | Yes |
| Maximum Data Transfer Rate | 1774 Mbit/s |
| Ethernet LAN Data Rates | 1000 Mbit/s |
| Networking Standards | IEEE 802.11ax, IEEE 802.11mc |
| MIMO | Yes |
| Spread Spectrum Method | DSSS, OFDM, OFDMA |
| Modulation | 16-QAM, 64-QAM, 256-QAM, 1024-QAM, BPSK, CCK, QPSK |
Ports & Interfaces
| Ethernet LAN (RJ-45) Ports | 1 |
| USB 2.0 Ports Quantity | 1 |
| USB Connector Type | USB Type-A |
Power
| Power Over Ethernet (PoE) | Yes |
| Power Consumption (max) | 16.5 W |
Design
| Product Colour | White |
| Cable Lock Slot | Yes |
| Cable Lock Slot Type | Kensington |
Antenna
| Antenna Features | Integrated antenna |
| Antennas Quantity | 2 |
Weight & Dimensions
| Width | 160 mm |
| Depth | 161 mm |
| Height | 37 mm |
| Weight | 500 g |
Operational Conditions
| Operating Relative Humidity (H-H) | 5 - 93% |
| Operating Temperature (T-T) | 0 - 50 °C |
| Storage Temperature (T-T) | -40 - 70 °C |
Warranty and Other
| Warranty Terms | 12 months |
| Product Condition | Original |
| Manufacturer Datasheet | https://www.tdbaltic.ee/leaflets/HPE/R2H28ALT.pdf |
