An all-in-one edge storage solution
The compact 1U 4-bay Synology RackStation RS822+/RS822RP+ with its storage and connectivity expandability coupled with the powerful Synology DiskStation Manager (DSM) operating system is an ideal edge storage solution for branch offices and small and medium-sized businesses.
Built for reliability
RS822+ comes with four Gigabit RJ-45 ports which can be bonded with Link Aggregation to enable automatic network failover and load balancing.
Two RS822+ units can be paired using Synology High Availability to form a reliable active/passive server cluster, maximizing service uptime.
All-in-one data management platform
The RS822+ is designed to support small deployments in tackling common applications such as file management, data backup, and surveillance.
Edge storage for distributed teams
Provide secure and convenient multi-platform file access, sharing, and synchronization across different locations.
Multi-endpoint data protection
Design an effective backup strategy to maximize system availability with a host of native and license-free solutions.
Smart surveillance for small deployments
Leverage flexible deployment options, intuitive management capabilities, and advanced video analytics to secure your premises.
Powered by Synology DSM
Take advantage of a whole host of native productivity, management, and security solutions available on the web-based DSM operating system.
Purchase a NAS together with Synology HAT series drives and benefit from the Synology Express Replacement Program, ensuring same-day drive replacement when needed. Contact your Sales Manager for more details.
- 2 GB DDR4 ECC SODIMM (Up to 32 GB DDR4 ECC)
- 4 x 3.5" or 2.5" SATA HDD/SSD
- AMD Ryzen processor
- 3 System fans (40 x 40 x 20 mm)
- AES-NI hardware encryption engine
General
| Unit Calculated Weight | 9.7 kg |
| Unit Calculated Volume | 0.072529 cubm |
| Units per Shipping Box | 1 |
| Summary | Synology RackStation RS822+. Type: NAS. Processor family: Ryzen Embedded, Processor model: V1500B, Processor frequency: 2.2 GHz. Internal memory: 2 GB, Internal memory type: DDR4. Operating system installed: DSM |
| Unit Box Height | 0.205 |
| Unit Box Length | 0.61 |
| Unit Box Width | 0.58 |
| Model name | RS822+ |
Storage
| Hot-swap drive bays | Yes |
| Installed storage drive type | No |
| Maximum supported storage capacity | 108 TB |
| Number of storage drives supported | 4 |
| RAID levels | 0/1/10/5/6/JBOD |
| RAID support | Yes |
| Storage drives installed | No |
| Supported file systems | BTRFS/exFAT/ext3/ext4/FAT32/HFS+/NTFS |
| Supported storage drive interfaces | Serial ATA |
| Supported storage drive types | HDD & SSD |
Processor
| On-board graphics card model | Not available |
| Processor cores | 4 |
| Processor family | Ryzen Embedded |
| Processor frequency | 2.2 GHz |
| Processor generation | AMD Ryzen Embedded V1000 Series |
| Processor manufacturer | AMD |
| Processor model | V1500B |
| Processor threads | 8 |
Memory
| Internal memory | 2 GB |
| Internal memory type | DDR4 |
| Maximum RAM supported | 32 GB |
| Memory form factor | SO-DIMM |
Network
| Supported network protocols | SMB, AFP, NFS, FTP, WebDAV, CalDAV, iSCSI, Telnet, SSH, SNMP, and VPN (PPTP, OpenVPNT, L2TP) |
| Wake-on-LAN ready | Yes |
Ports & interfaces
| eSATA ports quantity | 1 |
| Ethernet LAN (RJ-45) ports | 4 |
| PCI Express x8 (Gen 3.x) slots | 1 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 1 |
| USB port | Yes |
Design
| LED indicators | Alarm/Power/Status |
| Number of fans | 3 fan(s) |
Performance
| Access Control List (ACL) | Yes |
| Backup function | Yes |
| On/off switch | Yes |
| Reset button | Yes |
| Type | NAS |
Software
| Operating system installed | DSM |
Power
| AC input frequency | 50 - 60 Hz |
| AC input voltage | 100 - 240 V |
Weight & dimensions
| Depth | 457.6 mm |
| Height | 44 mm |
| Weight | 6400 g |
| Width | 430.5 mm |
Packaging content
| Cables included | AC |
Operational conditions
| Operating altitude | 0 - 5000 m |
| Operating relative humidity (H-H) | 8 - 80 % |
| Operating temperature (T-T) | 0 - 35 °C |
| Storage relative humidity (H-H) | 5 - 95 % |
| Storage temperature (T-T) | -20 - 60 °C |
Other features
| Certification | FCC CE BSMI VCCI RCM UKCA EAC CCC KC UL |
