RUT261 is a compact, cost-effective cellular LTE router designed to deliver fast and stable connectivity with 4G Cat 6, enabling optimal throughput for everyday operational needs. Its space-efficient housing integrates easily into tight or embedded installations, making it ideal for constrained environments. With dual Ethernet ports, the RUT261 covers essential LAN and WAN connectivity, ensuring reliable wired networking where needed. Focused on core functionality, it provides the essential features required for industrial deployments without added complexity or unnecessary costs, making RUT261 a practical and affordable choice for streamlined connectivity.
COST EFFECTIVE 4G CAT 6
Optimize daily operations with low price LTE Cat 6 speeds
COMPACT FORM FACTOR
Integrates into tight or embedded setups with its compact housing
DUAL ETHERNET
Covers essential LAN and WAN connectivity
ZERO TOUCH DEPLOYMENT
Manage devices, perform maintenance, enable VPN access, and gather data through RMS.
- COST EFFECTIVE 4G CAT 6
- COMPACT FORM FACTOR
- DUAL ETHERNET
- ZERO TOUCH DEPLOYMENT
General
| Unit Calculated Weight | 0.56 kg |
| Unit Calculated Volume | 0.003308 cubm |
| Units per Shipping Box | 1 |
| Units per Pallet | 0 |
| Summary | Teltonika RUT261. Device type: Cellular network router, Product colour: Black, Housing material: Aluminium, Plastic. Ethernet LAN interface type: Fast Ethernet, Ethernet LAN data rates: 10,100 Mbit/s, Networking standards: IEEE 802.11s, IEEE 802.11r, IEEE 802.11v, IEEE 802.11k, IEEE 802.3, IEEE 802.3u, IEEE 802.3az,.... Wi-Fi standards: 802.11b, 802.11g, Wi-Fi 4 (802.11n). Data network: 4G, 3G, 4G standard: LTE, SIM card type: MiniSIM. Security algorithms: SSID, 3DES, DES, 128-bit AES, 192-bit AES, 256-bit AES, Authentication method: Pre-shared key, digital certificates, X.509 certificates, TACACS+, Internal & External RADIUS... |
| CnCode | 85176200 |
| Unit Box Height | 0.07 |
| Unit Box Length | 0.315 |
| Unit Box Width | 0.15 |
| Model name | RUT261 |
Design
| Built-in display | No |
| Device type | Cellular network router |
| Housing material | Aluminium/Plastic |
| LED indicators | LAN/Power/Status/WAN |
| Market positioning | Business |
| Mounting | DIN-rail/Wall mounting |
| Product colour | Black |
| Reset button | Yes |
Ethernet LAN features
| Auto MDI/MDI-X | Yes |
| DHCP client | Yes |
| DHCP server | Yes |
| Dynamic DNS (DDNS) | Yes |
| Ethernet LAN | Yes |
| Ethernet LAN data rates | 10/100 Mbit/s |
| Ethernet LAN interface type | Fast Ethernet |
| IP routing | Yes |
| MAC address filtering | Yes |
| Network bridge | Yes |
| Networking standards | IEEE 802.11e/IEEE 802.11k/IEEE 802.11r/IEEE 802.11s/IEEE 802.11v/IEEE 802.1x/IEEE 802.3/IEEE 802.3az/IEEE 802.3u |
| Supported network protocols | TCP, UDP, IPv4, IPv6, ICMP, NTP, DNS, HTTP, HTTPS, SFTP, FTP, SMTP, SSL/TLS, ARP, VRRP, PPP, PPPoE, UPNP, SSH, DHCP, Telnet, SMPP, SNMP, MQTT, Wake On Lan (WOL), VXLAN |
| VoIP | Yes |
| VPN Passthrough | Yes |
Wireless LAN features
| Bluetooth | No |
| Number of WLAN connections (max) | 50 |
| Wi-Fi | Yes |
| Wi-Fi standards | 802.11b/802.11g/Wi-Fi 4 (802.11n) |
Mobile network
| 4G LTE category | 6 |
| 4G standard | LTE |
| Data network | 3G/4G |
| Data transfer rate (LTE) (download) | 300 Mbit/s |
| Data transfer rate (LTE) (upload) | 50 Mbit/s |
| Number of SIM cards | 1 |
| Number of simultaneous SIM cards | 1 |
| Short Message Service (SMS) | Yes |
| SIM card type | MiniSIM |
Ports & interfaces
| Card reader integrated | No |
| Ethernet LAN (RJ-45) ports | 2 |
| USB port | No |
Security
| Authentication method | Pre-shared key, digital certificates, X.509 certificates, TACACS+, Internal & External RADIUS users authentication, IP & login attempts block, time-based login blocking, built-in random password generator |
| Firewall | Yes |
| Security algorithms | 128-bit AES/192-bit AES/256-bit AES/3DES/DES/SSID |
Certificates
| Certification | E-Mark, UCRF |
| Compliance certificates | CB/CE/EAC/RCM/REACH/RoHS/UKCA |
| Waste Electrical and Electronic Equipment (WEEE) compliance | Yes |
Sustainability
| Doesn't contain | Cadmium/Lead/Mercury |
Performance
| Antenna connector type | SMA/RP-SMA |
| Antenna type | External |
| Antennas quantity | 3 |
| Built-in processor | Yes |
| Internal storage capacity | 0.032 GB |
| International Protection (IP) code | IP30 |
| Management protocols | HTTP(S), MQTT, Azure MQTT |
| Operating system installed | RutOS |
| Processor manufacturer | Mediatek |
| RAM capacity | 0.128 GB |
| RAM type | DDR2 |
Power
| Input voltage | 9 - 30 V |
| Power consumption (max) | 3.5 W |
| Power source type | DC,PoE |
Operational conditions
| Operating relative humidity (H-H) | 10 - 90 % |
| Operating temperature (T-T) | -40 - 75 °C |
Weight & dimensions
| Depth | 74 mm |
| Height | 25 mm |
| Weight | 132 g |
| Width | 83 mm |
Packaging data
| Package depth | 148 mm |
| Package height | 71 mm |
| Package width | 173 mm |
Logistics data
| Country of origin | Lithuania |
