Fast and capacious
With read speeds of up to 3,500 MB/s and write speeds of up to 2,800 MB/s, you’ll experience fast program loading and lightning-fast transfers for the ultimate working experience. Forget about long application loads or slow system loads. The drive’s capacities allow you to store huge amounts of data, including large files, multimedia, applications and even the operating system, without worrying about running out of storage space.
Flagship technologies
Utilising a PCIe 3 x4 interface, the PX500 gen. 3 drive guarantees great throughput and performance even during heavy use, which is crucial for compute-intensive applications and fast data access. The drive incorporates a number of technologies that not only improve performance, but also enhance the durability and security of stored data. These include: Error Correction Code (ECC), Wear leveling, Thermal throttling or the SMART function.
General
| Unit Calculated Weight | 0.025 kg |
| Unit Calculated Volume | 0.0001867 cubm |
| Units per Shipping Box | 10 |
| Units per Pallet | 0 |
| Summary | Goodram PX500 gen. 3. SSD capacity: 1 TB, SSD form factor: M.2, Read speed: 3300 MB/s, Write speed: 2700 MB/s, Component for: PC |
| CnCode | 84717098 |
| Unit Box Height | 0.14 |
| Unit Box Length | 0.14 |
| Unit Box Width | 0.005 |
Features
| Component for | PC |
| ECC | Yes |
| Hardware encryption | No |
| Interface | PCI Express 3.0 |
| M.2 key ID | M |
| M.2 SSD size | 2280 (22 x 80 mm) |
| Mean time between failures (MTBF) | 1500000 h |
| Memory type | 3D NAND |
| NVMe | Yes |
| NVMe version | 1.4 |
| PCI Express interface data lanes | x4 |
| Random read (4KB) | 230000 IOPS |
| Random write (4KB) | 300000 IOPS |
| Read speed | 3300 MB/s |
| S.M.A.R.T. support | Yes |
| SSD capacity | 1000 GB |
| SSD form factor | M.2 |
| TBW rating | 600 |
| Write speed | 2700 MB/s |
Weight & dimensions
| Depth | 80 mm |
| Height | 3.8 mm |
| Weight | 7 g |
| Width | 22 mm |
Packaging data
| Manual | Yes |
| Package depth | 8 mm |
| Package height | 140 mm |
| Package type | Blister |
| Package weight | 22.5 g |
| Package width | 140 mm |
Operational conditions
| Operating temperature (T-T) | 0 - 70 °C |
| Storage temperature (T-T) | -40 - 85 °C |
