SkyHawk™ leverages Seagate's extensive experience in designing drives purpose-built for surveillance applications.
ImagePerfect™ firmware is designed to ensure seamless video footage capture in 24×7 surveillance workloads1 that record video from 64 HD cameras.
SkyHawk Health Management actively helps protect your surveillance storage by focusing on prevention, intervention, and recovery options.2 Included is RAID RapidRebuild™, which provides 3× faster volume rebuilds over traditional RAID rebuilds.
Unparalleled data protection with included 3-year Rescue Data Recovery Services plan, helping protect important video data with Seagate's in-house data recovery services.
RV sensors built in allow drives to maintain performance in multi-bay systems, giving customers the flexibility to scale their systems when more storage is needed.
ATA streaming support enables recordings from up to 64 HD cameras for smooth, uninterrupted footage.
1 M hours MTBF, 3-year limited warranty represents an improved total cost of ownership (TCO) with reduced maintenance costs.
Lower power consumption means a reduction in heat emissions, which improves reliability in surveillance solutions. Tarnish-resistant components help protect drive from environmental elements, increasing field reliability
General
| Summary | Seagate SkyHawk . HDD capacity: 2 TB, Storage drive buffer size: 256 MB, HDD size: 3.5", Interface: Serial ATA III |
| Unit Box Height | 0.1 |
| Unit Box Length | 0.15 |
| Unit Box Width | 0.02 |
| Name | HDD SATA 2TB 5400RPM 256MB/ST2000VX017 SEAGATE |
| HDD Family name | SkyHawk |
| Model | ST2000VX017 |
Features
| Mean time between failures (MTBF) | 1000000 h |
| Workload rate limit | 180 TB/year |
| Start/stop cycles | 600000 |
| RV sensor(s) | Yes |
| 24/7 operation | Yes |
| Rotational Vibration (RV) sensors | Yes |
| Uncorrectable Bit Error Rate (UBER) | < 1 per 10^14 bits read |
| HDD sustained transfer rate | 180 MiB/s |
| HDD interface transfer rate | 6 Gbit/s |
| Component for | PC |
| Type | HDD |
| Interface | Serial ATA III |
| HDD size | 3.5 " |
| Storage drive buffer size | 256 MB |
| HDD capacity | 2000 GB |
Power
| Start-up current | 1.8 A |
| Power consumption (idle) | 2.5 W |
| Power consumption (off) | 0.25 W |
| Power consumption (typical) | 3.7 W |
Operational conditions
| Operating temperature (T-T) | 0 - 60 °C |
Weight & dimensions
| Weight | 415 g |
| Depth | 146.99 mm |
| Height | 20.2 mm |
| Width | 101.6 mm |
Other features
| Maximum number of cameras supported | 64 |
ELKO Logistics Data
| Unit Height | 10 cm |
| Unit Depth | 15 cm |
| Unit Width | 2 cm |
| Units per Pallet | 0 |
| Units per Shipping Box | 25 |
| Product Net Weight | 0.415 kg |
| Unit Calculated Weight | 0.434 kg |
ELKO Internal Logistics Data
| Shipping Box Width | 22 cm |
| Shipping Box Depth | 50 cm |
| Shipping Box Height | 29.5 cm |
| Shipping Box Weight | 10.8500003815 kg |
| Unit Calculated Volume | 0.001298 cubm |
