Power Your 360° Vision with 3K Clarity
Outdoor Pan/Tilt Security Wi-Fi Camera
Capture Every Detail, Day and Night
With 3K resolution, Tapo C530WS offers enhanced video quality better than 1080P.
Enjoy colorful images in low-light conditions at night with built-in spotlights and a starlight sensor. With smart mode, the live view turns from black and white to color after detecting person.
AI Detection for More Relevant Notifications
Smart AI accurately identifies people, pets, and vehicles and detects tampering and line crossing. It sends instant notifications when specific objects are detected, ensuring you receive timely and precise alerts.
Long-Range Uninterrupted Connectivity
Dual high-performance external antennas extend wireless coverage up to 492 ft in open areas. You can also connect your camera to the network through the Ethernet port for a stable connection.
Designed to Withstand Extreme Conditions
With IP66 weatherproofing, Tapo C530WS offers excellent waterproof and dustproof performance for outdoor scenarios. It works well in rain, dust, and heat, operating reliably in different environments.
Custom Sound and Light Alarm
Customize your own audio alarm to frighten away unwanted visitors. Adjust two built-in spotlights for fine-tuned illumination.
24/7 Secure Local & Cloud Storage
Save crucial moments to a microSD card† (up to 512 GB) or subscribe to Tapo Care for cloud storage‡ after a 30-day free trial, ensuring you never lose important footage.
Multiple Installation Options
Use the mounting screws, template, and loops△ to install on any wall, ceiling, or pole for the perfect view—wherever you want.
Customizable Activity Zone
Customize detection zones to receive alerts for your most important areas.
Two-Way Audio
Communicate directly with the outdoors for your convenience.
Physical Privacy Mode
Maintains your privacy with the lens physically blocked by the housing.
- 3K 5MP Live View-Adopting a 2880 × 1620 resolution, Tapo C530WS offers enhanced video quality to see more details
- Starlight Color Night Vision-Enhances your security by revealing brighter, full-color images and vivid details even in low-light conditions with built-in spotlights and the starlight sensor
- 360° All-Round Protection-Enjoy 360° horizontal and 130° vertical views with motion tracking to eliminate blind spots. Activate patrol mode to cruise among multiple custom points
- Comprehensive AI Detection-Smart AI accurately identifies people, pets, and vehicles while featuring tamper and line-crossing detection, minimizing false alerts and unnecessary notifications
- Flexible Connections & Reliable Networking-Connect your camera via Wi-Fi or Ethernet for flexible installation. Powerful dual antennas ensure connectivity up to 492ft in open areas.*
- IP66 Weatherproofing-Offers excellent waterproof and dustproof performance for outdoor scenarios. It works well in rain, dust, and heat
- Customizable Sound and Light Alarm-The ultra-bright adjustable light deters unwanted visitors, while custom audio alarms offer further use
- Secure Local & Cloud Storage-Save crucial moments to a microSD card† (up to 512 GB) or subscribe to Tapo Care for cloud storage‡ after a 30-day free trial, ensuring you never lose important footage
- Two-Way Audio-Enables communication through a built-in microphone and speaker
General
| Unit Calculated Weight | 0.733 kg |
| Unit Calculated Volume | 0.005548 cubm |
| Units per Shipping Box | 12 |
| Units per Pallet | 0 |
| Summary | TP-Link Outdoor Pan/Tilt Security Wi-Fi Camera SPEC: 3K 5MP (2880x1620), 2.4 GHz, 2 × External Antennas, 1 × Ethernet Port, Horizontal 360º. Type: IP security camera, Placement supported: Outdoor, Connectivity technology: Wired & Wireless. Mounting type: Wall, Product colour: White, Form factor: Turret. Lens viewing angle, horizontal: 95°, Lens viewing angle, vertical: 53°, Lens viewing angle, diagonal: 112°. Sensor type: CMOS, Optical sensor size: 25.4 / 3 mm (1 / 3"). Sensor type (panoramic camera): CMOS |
| Unit Box Height | 0.145 |
| Unit Box Length | 0.21 |
| Unit Box Width | 0.16 |
| Model name | Outdoor Pan/Tilt Security Wi-Fi Camera SPEC: 3K 5MP (2880x1620), 2.4 GHz, 2 × External Antennas, 1 × Ethernet Port, Horizontal 360º |
| Model | TP-LINK TAPO C530WS |
Performance
| Antenna type | External |
| Antennas quantity | 2 |
| Auto pan mode | Yes |
| Connectivity technology | Wired & Wireless |
| Day/night mode | Yes |
| Maximum operating distance | 29.9 m |
| Placement supported | Outdoor |
| Remote viewing | Yes |
| Type | IP security camera |
Design
| Form factor | Turret |
| Housing material | Metal |
| International Protection (IP) code | IP66 |
| Mounting type | Wall |
| Product colour | White |
| Protection features | Waterproof |
| Weatherproof | Yes |
Camera
| Camera pan control | Yes |
| Camera tilt control | Yes |
| Lens viewing angle, diagonal | 112 ° |
| Lens viewing angle, horizontal | 95 ° |
| Lens viewing angle, vertical | 53 ° |
| Tilt angle range | 60 - 130 ° |
Image sensor
| Optical sensor size | 1/3 " |
| Progressive scan | Yes |
| Sensor type | CMOS |
Panoramic camera
| Sensor type (panoramic camera) | CMOS |
Lens system
| Digital zoom | 12 x |
| Focal length range | 3.2 mm |
Night vision
| LED type | IR/White |
| Night vision | Yes |
Video
| Frame rate | 30 fps |
| Image quality adjustment | DNR |
| Maximum resolution | 2880 x 1620 pixels |
| Supported graphics resolutions | 2880 x 1620 |
| Total megapixels | 5 MP |
| Video compression formats | H.264 |
| Video recording | Yes |
Audio
| Audio detection | Yes |
| Audio formats supported | RTSP |
| Audio input channels | 1.0 channels |
| Audio output channels | 1.0 channels |
| Audio system | 2-way |
| Built-in microphone | Yes |
| Built-in speaker(s) | Yes |
| Number of microphones | 1 |
Network
| Bluetooth | No |
| Ethernet LAN | Yes |
| Live view | Yes |
| Networking standards | IEEE 802.11ax/IEEE 802.11b/IEEE 802.11g/IEEE 802.11n |
| Wi-Fi | Yes |
| Wi-Fi standards | 802.11b/802.11g/Wi-Fi 4 (802.11n) |
Storage
| Compatible memory cards | MicroSD (TransFlash) |
| Maximum memory card size | 512 GB |
Ports & interfaces
| Ethernet LAN (RJ-45) ports | 1 |
Security
| Alert notification type | Push notification |
| Built-in siren | Yes |
| HTTPS encryption | Yes |
| Mirror | Yes |
| Motion sensor | Yes |
| Siren noise level | 99 dB |
| Video motion detection | Yes |
Management features
| Cloud-managed | Yes |
| Remotely operated | Yes |
| Reset button | Yes |
Power
| AC input frequency | 50/60 Hz |
| AC input voltage | 100 - 240 V |
| DC output current | 0.85 A |
| DC output voltage | 9 |
| Power source type | AC,DC |
Operational conditions
| Operating relative humidity (H-H) | 10 - 90 % |
| Operating temperature (T-T) | -30 - 60 °C |
| Storage relative humidity (H-H) | 0 - 90 % |
| Storage temperature (T-T) | -40 - 60 °C |
Weight & dimensions
| Depth | 90 mm |
| Height | 123 mm |
| Width | 123.8 mm |
Packaging data
| Package depth | 210 mm |
| Package height | 145 mm |
| Package type | Box |
| Package weight | 740 g |
| Package width | 160 mm |
Packaging content
| Drilling template included | Yes |
| Manual | Yes |
| Mounting brackets included | Yes |
| Mounting kit | Yes |
| Number of cameras | 1 |
| Screws included | Yes |
