> Full metal casing design.
> Customizable Number of Buttons (1, 2 or 4 button sets included).
> 1/2.8" 2-MP HD CMOS camera.
> Offers two–way video call with indoor monitors.
> IR illumination and auto WDR.
> Supports two locks.
> Voice call and unlocking through app.
> Two wires and RJ-45 connection.
> IK08 and IP65 rated.
> H.264 and H.265.
> Unlock with IC card.
> PoE power supply.
> Included rain cover.
> Optional red-brown or dark blue front cover.
General
| Unit Box Height | 0.083 |
| Power supply requirements | 48 VDC, 1 A |
| Unit Box Length | 0.25 |
| Unit Box Width | 0.167 |
| Operating temperature range | –40 °C to +60 °C |
| Dimensions | 188.1 mm × 107.2 mm × 30 mm |
| Units per Shipping Box | 1 |
| Unit Calculated Volume | 0.003465 cubm |
| Product Net Weight | 0.57 kg |
| Unit Calculated Weight | 0.82 kg |
Input/Output connectors
| Alarm In | 1 |
| Alarm Out | 1 |
| Audio-In | 1 |
| Audio-Out | 1 |
| MicroSD Card Slot | 1 |
| RJ45 | 1 |
| RS-485 | 1 |
