- Motorized desk frame
- Single motor
- Load capacity: 70 kg
- Compatible tabletop size: (1200–1700 mm) × (600–750 mm).
- Height adjustment: 710 – 1180 mm
- Lifting speed: 25 mm/s
- Motor power: 52.2 W
- Maximum noise level: 50 dB
- Power supply: 100-240 V
- Power cord length: 1.5 m
- Frame width adjustment: 1000 – 1400 mm
- Certification: CE, UL, FCC for power supply
- Material: cold-rolled steel
General
| Unit Calculated Weight | 14.5 kg |
| Unit Calculated Volume | 0.03811 cubm |
| Units per Shipping Box | 1 |
| Units per Pallet | 0 |
| Summary | ONKRON WDF221E-B. Maximum weight capacity: 70 kg, Height adjustment type: Electric, Maximum speed: 25 mm/sec. Minimum height: 71 cm, Maximum height: 118 cm. Package width: 1044 mm, Package depth: 375 mm, Package height: 105 mm. AC adapter input voltage: 100-240 V |
| Unit Box Height | 0.1 |
| Unit Box Length | 1.03 |
| Unit Box Width | 0.37 |
| Model | WDF221E |
Features
| Certification | CE, UL, FCC |
| Compatible desk top depth (max) | 750 mm |
| Compatible desk top depth (min) | 600 mm |
| Compatible desk top width (max) | 1700 mm |
| Compatible desk top width (min) | 1200 mm |
| Frame colour | Black |
| Height adjustment | Yes |
| Height adjustment type | Electric |
| Maximum speed | 25 mm/sec |
| Maximum weight capacity | 70 kg |
| Number of legs | 2 leg(s) |
| Number of motors | 1 |
| Shape | Straight |
Weight & dimensions
| Maximum height | 1180 mm |
| Minimum height | 710 mm |
Power
| AC adapter input voltage | 100-240 V |
Packaging data
| Package depth | 375 mm |
| Package height | 105 mm |
| Package type | Box |
| Package weight | 13450 g |
| Package width | 1044 mm |
